2-Person Back-to-Back Industrial Office Workstation with Mesh Dividers and Integrated Pedestals,型号 WS2P-IND-MESH-1680,归属“开放式工作站”栏目,整体尺寸 1680 × 1250 × 760 mm,主材为Particle‑board (PB)。承重参数:113 kg。认证标签:Industrial,style,back-to-back,2-person,layout,integrated,storage,cable,management,low,metal,privacy,dividers。本页汇总该型号 6 类产品参数及 GB / EN / ANSI/BIFMA 标准参考,支持公制与英制单位切换,目前已登记 1 家供应商,可直接发起询价。
| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
暂无参数纠错记录,发现错误可点击行末旗标提交 | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| Overall dimensions | 1680 x 1250 x 760 mm | |
|---|---|---|
| Per-user desktop workspace | 1680 x 625 mm | |
| Desktop panel thickness | 25 mm | |
| PVC edge banding thickness | 3 mm | |
| Seated knee clearance height under desk | 670 mm | |
| Knee clearance depth per user | 450 mm | |
| Integrated end pedestal dimensions | 400 x 500 x 650 mm | |
| Desktop cable grommet diameter | 76 mm | |
| Metal mesh privacy divider height | 300 mm | |
| Hairpin leg rod diameter | 12 mm | |
| Central cable management compartment width | 880 mm | |
| Adjustable leveling foot height adjustment | 15 mm | |
| Drawer internal usable height per pedestal | 150 mm (top drawer), 300 mm (lower file drawer) | |
| Vented cable access panel slot size | 150 x 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Static desktop load capacity per user zone | 113 kg | |
|---|---|---|
| Drawer slide load rating per drawer | 25 kg | |
| Drawer slide cycle rating | 50000 open/close cycles | |
| Unit net weight | 150 kg | |
| Recommended user weight capacity per station | 136 kg | |
| Surface abrasion resistance rating | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Desktop core and surface | 25 mm E1-grade engineered particleboard with thermally fused distressed light wood melamine | |
|---|---|---|
| Structural frame and legs | 12 mm diameter powder-coated dark gray steel hairpin legs with X-brace cross support | |
| Privacy dividers | 4 mm diameter dark gray steel wire with diamond mesh pattern, fixed with metal base mounts | |
| Pedestal panels | 18 mm matching melamine engineered wood with dark gray powder-coated steel drawer fronts | |
| Edge protection | 3 mm thick impact-resistant PVC edge banding on all exposed desktop edges | |
| Hardware and accessories | Zinc-plated steel cam lock fasteners, plastic leveling glides, plastic cable grommet covers |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Storage function | Two integrated 2-drawer pedestals at outer ends, each with one lock securing both supply and file drawers | |
|---|---|---|
| Cable management | Dual desktop grommets, central vented under-desk cable compartment, routed access to floor power outlets | |
| Privacy separation | Low-profile diamond mesh dividers between opposing work zones for visual privacy without blocking overhead light | |
| Stability adjustment | Height-adjustable leveling glides on all cabinet base feet to compensate for uneven flooring |
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Open-plan office staff zones | Provides two dedicated workspaces with built-in storage for team seating areas | |
|---|---|---|
| Small business and startup offices | All-in-one workstation with cable management and storage reduces fitout costs |
欧洲市场准入与化学品要求
| EN 527-1:2011 | Office work tables and desks, safety and strength requirements for commercial office use | |
|---|---|---|
| EN 15372:2016 | Furniture strength, durability and safety requirements for non-domestic storage units in pedestals |
美国及加拿大家具标准
| ANSI/BIFMA X5.5-2021 | Desk products standard for structural performance, load capacity and durability testing | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer slide performance and pedestal structural integrity |
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desktop and storage panel structural performance | |
|---|---|---|
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables, applicable to desktop static load and stability testing | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable to engineered wood core material emission testing |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to desktop and storage panel structural performance; 2. GB/T 10357.1-2013:Furniture mechanical performance test for tables, applicable to desktop static load and stability testing; 3. GB 18580-2017:Formaldehyde emission limit for wood-based panels, applicable to engineered wood core material emission testing; 最终交付参数、检测报告和验收标准以双方采购合同为准。
