4-Person Back-to-Back Office Workstation with Privacy Dividers, Integrated Storage and Power Outlets Specifications

WS-4P-BB-2830

代码:6LHWZRV1

4-Person Back-to-Back Office Workstation with Privacy Dividers, Integrated Storage and Power Outlets,型号 WS-4P-BB-2830,归属“开放式工作站”栏目,整体尺寸 2830 × 1200 × 750 mm,净重 100 kg,主材为Particle‑board (PB)。承重参数:113 kg。认证标签:modular,structure,integrated,storage,desktop-mounted,privacy,dividers,built-in,power,outlets,white-gray,color,scheme。本页汇总该型号 6 类产品参数及 GB / EN / ANSI/BIFMA 标准参考,支持公制与英制单位切换,目前已登记 1 家供应商,可直接发起询价。

获取供应商报价
2026-10-07 14:34人气: 3
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

WS-4P-BB-2830

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源:工厂资料结构化字段,最终以实测值为准

Overall workstation dimensions2830 x 1200 x 1100 mm
Standard work surface height750 mm
Per individual work position width1200 mm
Per individual work position depth600 mm
Under-desk knee clearance height670 mm
Desktop panel thickness25 mm
Privacy divider height above desktop350 mm
Privacy divider thickness41 mm
Support leg square tube section44 mm
Cable grommet diameter60 mm
Drawer front height (small top drawer)120 mm
Drawer front height (large lower storage drawer)480 mm
Open under-desk cubby dimensions300 x 400 x 500 mm
PVC edge banding thickness2 mm
Leveling foot adjustment range15 mm
Finished Top Thickness50 mm
Effective Knee Clearance680 mm high and 900 mm wide per main seat
Leg / Support Section80 mm main section with 2 mm metal wall
Cable Opening Size80 mm diameter; cable tray depth 120 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源:产品性能数据,采购前请核对具体测试口径

Per work position desktop static load capacity113 kg
Drawer slide cycle durability50000 cycles
Integrated power outlet AC rating12A 120V
Workstation total gross weight100 kg
Recommended maximum user weight per position136 kg
Surface scratch resistance rating2000 cycles
Product warranty period7 years
Top Static Load Reference150 kg uniformly distributed
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening LifeAcceptance target 80000 cycles
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源:以工厂材质清单与验货报告为准

Work surface25mm E1 grade melamine-faced particleboard, 2mm PVC edge banding
Support frame and legsPowder-coated square steel tube, matte dark gray finish
Privacy dividersFabric-wrapped tackable MDF core, muted sage green finish
Drawer and cabinet panels18mm melamine-faced particleboard, white and dark gray two-tone finish
Drawer hardwareThree-section full-extension ball-bearing steel slides, integrated keyed drawer locks
Cable management componentsABS plastic cable grommets, under-desk steel cable trays
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源:功能配置参数,以供应商正式规格为准

Privacy partition functionLow desktop-mounted dividers separate opposite-facing users to reduce visual distraction
Integrated power accessDual AC power outlets mounted on each divider support direct device charging and power
Cable management systemDesktop grommets and under-desk trays route cables to floor outlets without clutter
Integrated storage functionEach position includes 1 lockable small drawer, 1 lockable large file drawer, 1 open cubby
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源:外贸报价与装柜测算参考

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package DimensionsMain top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight180 kg/set in 4 cartons
Reference Packaging Volume1 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源:依据产品结构与品类整理的推荐应用场景

Open plan office staff areasProvides four dedicated work positions with visual privacy and personal storage
Startup and co-working spacesModular design supports flexible workspace layout with integrated power access
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011Office work tables, safety and strength requirements, applicable to desktop load and stability
EN 527-2:2016Office work tables, mechanical safety requirements, applicable to adjustment mechanisms
EN 1335-1:2020Office furniture, office work chair dimensional coordination, applicable to knee clearance
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Desk products standard, applicable to load, durability and stability testing
ANSI/BIFMA X5.9-2019Storage units standard, applicable to drawer slide and cabinet load testing
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to desk panel performance
GB/T 3327-2017Technical requirements for office desks and tables, applicable to dimensional and load standards
GB 20286-2006Fire performance requirements for public place furniture, applicable to panel and fabric components
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to desk panel performance;
2. GB/T 3327-2017:Technical requirements for office desks and tables, applicable to dimensional and load standards;
3. GB 20286-2006:Fire performance requirements for public place furniture, applicable to panel and fabric components;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · WS-4P-BB-2830

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · WS-4P-BB-2830

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · WS-4P-BB-2830打开导出工具

页面快速操作

发布采购询价

产品描述

The YOUBILI WS-4P-BB-2830 4-Person Back-to-Back Office Workstation is a cluster desk solution built to balance collaborative access, individual focus, and organized utility for shared work environments. Presented in a clean white-gray color scheme with muted sage green privacy dividers, the unit arranges four individual work positions in a back-to-back layout, separated by low desktop-mounted partitions that sit above the work surface to cut down on visual distraction between opposite-facing users. Each position offers a dedicated work surface with standard ergonomic desk height and ample under-desk knee clearance, supported by a sturdy matte dark gray powder-coated square steel tube frame. All work surfaces are constructed from 25mm E1 grade melamine-faced particleboard with 2mm PVC edge banding, for a smooth, durable finish that resists regular daily wear. The privacy dividers feature a fabric-wrapped tackable MDF core, suitable for pinning quick notes or reference materials within easy reach, while drawer and cabinet panels use 18mm melamine-faced particleboard in a complementary two-tone white and dark gray finish. Functional design elements are integrated directly into the workstation to eliminate unnecessary add-on clutter. Each work position is fitted with dual AC power outlets mounted directly to the adjacent privacy divider, supporting convenient device powering and charging without running cords across desk surfaces. A streamlined cable management system uses desktop ABS plastic cable grommets and under-desk steel cable trays to route wiring cleanly to floor outlets. For personal storage, every position includes one lockable small drawer, one lockable large file drawer, and one open cubby for frequently accessed items; drawers operate on smooth three-section full-extension ball-bearing steel slides with integrated keyed locks for secure storage of personal or work materials. This workstation is well-suited for open plan office staff areas, where it delivers dedicated individual workspaces with consistent privacy and personal storage for four team members. Its modular structure also makes it a practical fit for startup and co-working spaces, supporting flexible workspace layout adjustments as team needs shift. When planning procurement, teams should account for the unit’s packaged weight and multi-carton shipping configuration, as well as the standard assembly time required per set. The product is backed by a 7-year warranty, and purchasers should confirm that on-site AC power specifications align with the integrated outlets’ rated capacity before installation.
