2-Person L-Shaped Office Workstation Desk with Integrated Privacy Divider and Attached Storage Return Specifications

WS-2P-L2475

代码:7JEDQ6V1
获取供应商报价
2026-08-27 17:54人气: 18
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

WS-2P-L2475

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall workstation dimensions2475 x 1425 x 1100 mm
Desktop work surface height750 mm
Desktop panel thickness25 mm
Privacy screen divider height above desktop350 mm
Privacy screen divider thickness100 mm
Under-desk seated knee clearance height690 mm
Under-desk seated knee clearance depth600 mm
Attached storage return cabinet width1200 mm
Storage cabinet depth400 mm
Individual drawer interior dimensions350 x 350 x 120 mm
PVC edge banding thickness2 mm
Cable grommet diameter80 mm
Finished Top Thickness50 mm
Effective Knee Clearance680 mm high and 900 mm wide per main seat
Leg / Support Section80 mm main section with 2 mm metal wall
Cable Opening Size80 mm diameter; cable tray depth 120 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Desktop static uniform load capacity122 kg
Drawer slide operational cycle rating50000 cycles
Surface scratch resistance rating2000 cycles
Workstation stable user capacity2 persons
Available finish color options30
Standard product warranty5 years
Top Static Load Reference150 kg uniformly distributed
Drawer Slide Load / Life45 kg/pair; 50000 cycles
Hinge Opening LifeAcceptance target 80000 cycles
Top Abrasion ReferenceAcceptance target ≥4,000 abrasion cycles or finish-system test
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Work surface topMelamine-faced MFC particle board
Desk end support panels18mm thick black melamine-laminated engineered wood panel
Privacy divider screenLight blue fabric-faced panel with internal support frame
Storage cabinet carcass16mm thick black melamine-laminated engineered wood
Drawer frontsLight wood grain melamine-laminated engineered wood
Edge protection2mm thick PVC edge banding on all exposed panel edges
Hardware componentsZinc-plated steel cam locks, screws and connector fittings
Leveling feetNylon-base adjustable leveling feet with steel threaded stems
Primary Panel Thickness25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness2 mm
Metal Frame Wall Thickness2 mm cold-rolled steel
Primary Connector SpecificationReference M6-M8 with at least 2 fixing points per main support
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Work zone separationFixed central privacy divider blocks direct line of sight between two adjacent users
Storage configurationIntegrated side return includes 2 smooth-gliding drawers, 1 upper open cubby, 1 lower open shelf
Cable managementDesktop cable grommets route power and data cords from work surface to floor
Assembly mechanismKnock-down cam-lock assembly requiring only standard screwdriver tools
Stability adjustmentIntegrated adjustable leveling feet compensate for uneven floor surfaces
Document storageLower open shelf sized to accommodate upright A4/letter size office binders and files
Surface protectionMelamine finish resists water spills, surface scratches and everyday stains
Modular compatibilityPre-drilled connector points allow linkage to adjacent workstation units
Cable Management CapacityReference capacity 10power/data cables; tray load 10 kg
Reference Reassembly CountMain joints should support 5controlled assembly cycles
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package DimensionsMain top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight180 kg/set in 4 cartons
Reference Packaging Volume1 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open plan office spacesProvides two dedicated work positions with visual privacy for general staff seating
Small business startup officesIntegrated storage reduces need for separate cabinets, maximizing limited floor space
Administrative department work areasCombines work surface and document storage for filing and daily office tasks
Co-working facility dedicated desksStandard commercial dimensions and durability suit shared rotating work use
Home office dual-workstation setupsL-shaped layout fits corner spaces for two people working from home
Temporary project team spacesModular design allows quick setup and reconfiguration for short-term project teams
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 527-1:2011Office work tables safety and strength requirements, applicable to structural performance
EN 527-2:2016Office work tables dimensional safety requirements, applicable to clearance dimensions
EN 13722:2004Furniture strength and durability test methods for storage units, applicable to cabinet and drawers
EN 12521:2015Furniture strength, durability and safety requirements for non-domestic seating adjacent use
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Desk products safety and performance standard, applicable to load and stability testing
ANSI/BIFMA X5.9-2019Storage units safety and performance standard, applicable to drawer and shelf testing
ANSI/BIFMA e3-2019Furniture sustainability standard, applicable to material and emissions requirements
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden furniture, applicable to desk panel and cabinet construction
GB/T 3327-2017Performance test methods for office desks and tables, applicable to load and stability validation
GB 18580-2017Formaldehyde emission limits for wood-based panels, applicable to all engineered wood components
GB/T 4897.3-2015Particle board specifications for furniture use, applicable to desktop and cabinet panels
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to desk panel and cabinet construction;
2. GB/T 3327-2017:Performance test methods for office desks and tables, applicable to load and stability validation;
3. GB 18580-2017:Formaldehyde emission limits for wood-based panels, applicable to all engineered wood components;
4. GB/T 4897.3-2015:Particle board specifications for furniture use, applicable to desktop and cabinet panels;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · WS-2P-L2475

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · WS-2P-L2475

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · WS-2P-L2475打开导出工具

页面快速操作

发布采购询价

产品描述

The WS-2P-L2475 unbranded 2-person L-shaped office workstation desk is a modern, space-efficient work solution engineered to support paired work needs across both commercial and residential settings. Its L-shaped layout arranges two dedicated work positions separated by a fixed central light blue fabric-faced privacy divider that rises above the desktop to block direct line of sight between adjacent users, balancing shared spatial efficiency with individual visual privacy. The design incorporates an attached storage return integrated directly into the desk frame, eliminating the need for freestanding supplementary storage units to preserve usable floor area. The workstation is built with durable, commercial-grade materials tailored for regular daily use. Work surfaces use melamine-faced MFC particle board with a 25mm primary panel thickness, finished with 2mm thick PVC edge banding on all exposed edges to protect against impact and wear. Support structures consist of 18mm thick black melamine-laminated engineered wood end panels, held together with zinc-plated steel cam locks, screws, and connector fittings for rigid, fixed panel construction. The internal frame-supported privacy divider delivers a soft visual barrier, while the integrated storage cabinet uses 16mm thick black melamine-laminated engineered wood for its carcass, paired with light wood grain melamine-laminated drawer fronts for a subtle, contemporary contrast. Nylon-base adjustable leveling feet with steel threaded stems are fitted to the base to compensate for uneven floor surfaces, ensuring consistent stability. Functional features are tailored to common office workflow needs. The integrated storage return houses two smooth-gliding drawers, one upper open cubby, and one lower open shelf sized to hold upright A4 and letter-size office binders and files. Desktop cable grommets route power and data cords neatly from the work surface to the floor to reduce cord clutter, while the melamine desktop finish resists water spills, surface scratches, and everyday stains for easy maintenance. The unit uses a knock-down cam-lock assembly system that requires only a standard screwdriver, with a typical assembly time of 40 minutes per set, allowing straightforward setup for temporary or permanent installations. This workstation suits a wide range of spaces. In commercial settings, it works effectively in open plan offices for general staff seating, small business startup offices where floor space is limited, administrative department areas that require integrated filing storage, co-working facilities for dedicated shared desk use, and temporary project team spaces that need quick, reconfigurable setups. It also fits residential home office layouts, as its L-shaped form fits neatly into corner spaces to support two people working from home. Available in 30 finish color options, the unit is backed by a 5-year standard warranty, and ships as a single set split across multiple cartons for manageable transport and placement. Procurement teams should plan for appropriate receiving and assembly support, as the packaged set has a gross weight of 180kg, and account for the desk’s fixed L-shaped footprint when allocating floor space for installation.
