基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2100 × 850 × 820 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Sofa seating capacity | 3 persons | |
|---|---|---|
| Armchair seating capacity | 1 person | |
| Sofa total recommended static load | 300 kg | |
| Armchair recommended static load | 120 kg | |
| Sofa net weight reference | 58 kg | |
| Seat cushion foam density | 35 kg/m3 | |
| Back cushion foam density | 28 kg/m3 | |
| Foam rebound performance | 40% | |
| Back-to-back upholstery seam pitch | 8 stitches per 100 mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Seat and back upholstery | Black coated fabric or faux leather with visible stitched cushion divisions; exact material grade requires supplier BOM confirmation | |
|---|---|---|
| Cushion structure | Polyurethane foam cores over a structural seat deck; thickness and density are engineering targets rather than visible labels | |
| Internal sofa frame | Hardwood and engineered-wood load-bearing frame suggested by upholstered block construction; supplier section drawing required | |
| Sofa base frame | Chrome-plated tubular steel cantilever sled legs visible at both ends of the sofa | |
| Armchair base frame | Continuous chrome-plated tubular steel sled base visible under the armchair | |
| Padded armrests | Rectangular upholstered arm pads over a rigid structural arm frame; material layer build requires BOM confirmation |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Seating layout | Fixed three-seat sofa plus one matching single-seat armchair for grouped reception seating | |
|---|---|---|
| Base support | Open cantilever sled bases provide floor clearance of 150 mm and no moving parts | |
| Cushion configuration | Three independent seat cushions and three back cushions maintain separated occupant positions | |
| Floor protection | Continuous sled tubes require polymer floor glides at contact points; glide material is not visible |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Reception and guest lounge | Suitable for corporate reception areas because the three-seat sofa and single chair provide four defined visitor seats | |
|---|---|---|
| Executive meeting lounge | Suited to an executive office or informal meeting zone where compact black upholstery and metal sled bases support a formal appearance |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
本产品须满足以下技术参数要求: 1. 技术标准与检测报告由供应商在投标或采购确认阶段提供; 最终交付参数、检测报告和验收标准以双方采购合同为准。
