基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1800 × 750 × 780 mm | |
|---|---|---|
| Large nesting coffee table dimensions | 800 x 800 x 450 mm | |
| Small nesting coffee table dimensions | 600 x 600 x 420 mm | |
| Sofa seat height from floor | 430 mm | |
| Sofa seat depth | 580 mm | |
| Sofa backrest height above seat | 350 mm | |
| Armrest height above seat | 180 mm | |
| Sofa leg height | 180 mm | |
| Clearance under sofa/ chairs | 150 mm | |
| Upholstery seat cushion thickness | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| 3-seat sofa net weight | 55 kg | |
|---|---|---|
| 3-seat sofa total static load capacity | 360 kg | |
| Recommended total seating capacity | 5 persons | |
| Seat cushion indentation load deflection (ILD) | 40 | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Seam tensile strength | 180 N | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Seat and inner back upholstery | Off-white matte faux leather, 1.2mm thickness | |
|---|---|---|
| Outer back and arm outer panel upholstery | Dark grey matte faux leather, 1.2mm thickness | |
| Sofa and chair inner frame | Kiln-dried solid hardwood + 12mm plywood, screwed and doweled construction | |
| Seat support base | 4mm thick sinuous spring suspension + 20mm elastic webbing | |
| Seat cushion core | 40kg/m³ high resilience polyurethane foam, wrapped with 20g non-woven fabric | |
| Back cushion core | 30kg/m³ soft polyurethane foam | |
| Sofa and chair legs | 30mm diameter powder-coated matte black metal, tapered design, with plastic floor glides | |
| Coffee table and side table tops | 12mm thick white sintered stone with subtle marble veining, polished edge finish | |
| Table support frames | 20mm diameter powder-coated matte black metal tube, with circular ring base for stability | |
| Seam trim detail | 3mm dark contrasting piping along upholstery panel edges | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Seating configuration | Fixed 3+1+1 layout, non-modular, no recline or adjustment mechanisms | |
|---|---|---|
| Nesting coffee table function | Two round tables of differing heights nest together to save space when not in use, can be pulled apart for expanded surface area during meetings | |
| Floor protection design | All seating and table legs fitted with non-scratch plastic glides, prevents damage to commercial carpet or hard flooring | |
| Cleaning access | 150mm floor clearance under all units allows standard commercial vacuum and cleaning tools to pass underneath | |
| Upholstery maintenance | Smooth faux leather surface can be wiped clean with standard commercial upholstery cleaners, resists liquid spills for reception environments | |
| Stability design | All tables use full circular ring base frames to prevent tipping when weight is placed on table edges, no individual pointed leg contact points | |
| Armrest integration | Curved wrap-around armrests are integrated into the upholstered frame, no separate hard arm surfaces, provides continuous soft support along seated user sides | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Total shipping pieces per full set | 6 pieces | |
|---|---|---|
| Sofa carton dimensions | 1830 x 780 x 520 mm | |
| Single armchair carton dimensions | 810 x 750 x 500 mm | |
| Table set carton dimensions | 820 x 820 x 220 mm | |
| Total gross weight per full set | 120 kg | |
| Total CBM per full set | 1.35 m³ | |
| On-site assembly time | 45 minutes | |
| 20ft GP container loading quantity | 18 sets | |
| 40ft HQ container loading quantity | 46 sets | |
| Reference Package Count | 1 set / 2 cartons |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Corporate office reception areas | Formal two-tone design creates a professional first impression for visiting clients, seating arranged for face-to-face greeting conversations | |
|---|---|---|
| Executive waiting lounges | Medium-firm cushioning supports comfortable 30 minute waits for meeting attendees, easy-clean upholstery resists wear from daily visitor traffic | |
| Small meeting breakout spaces | Nesting tables can be repositioned to hold documents, laptops and beverages during informal team discussions, seating supports up to 5 participants | |
| Hotel lobby guest seating zones | Neutral color palette coordinates with most commercial interior finishes, compact footprint fits small lobby nooks without blocking circulation paths | |
| Medical office waiting areas | Smooth non-porous upholstery allows frequent sanitization between patients, no fabric traps for dust or allergens, stable leg design prevents tipping | |
| Recommended complementary configuration | Pair with matching wall-mounted magazine racks and floor lamps to create a complete welcoming reception zone; tables accommodate standard beverage service and printed materials | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| Recommended standard for office seating safety | EN 16139:2013 | |
|---|---|---|
| Recommended standard for furniture surface resistance | EN 12720:2009+A1:2013 | |
| Recommended standard for furniture flame retardancy | EN 1021:2014 |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| Recommended standard for lounge seating performance | ANSI/BIFMA X2021 | |
|---|---|---|
| Recommended standard for occasional tables performance | ANSI/BIFMA X2021 |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| Recommended standard for upholstered furniture safety | GB 28007 | |
|---|---|---|
| Recommended standard for furniture formaldehyde emission | GB 18584 | |
| Recommended standard for furniture mechanical performance | GB/T 3324 |
本产品须满足以下技术参数要求: 1. Recommended standard for upholstered furniture safety:GB 28007; 2. Recommended standard for furniture formaldehyde emission:GB 18584; 3. Recommended standard for furniture mechanical performance:GB/T 3324; 最终交付参数、检测报告和验收标准以双方采购合同为准。
