基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1760 × 840 × 890 mm | |
|---|---|---|
| seat width | 1510 mm | |
| seat depth | 660 mm | |
| seat height from floor | 480 mm | |
| backrest height | 410 mm | |
| armrest width | 200 mm | |
| armrest height from seat | 200 mm | |
| floor clearance under seat | 200 mm | |
| leg height | 200 mm | |
| minimum required entry door width | 800 mm | |
| Seat Cushion Thickness | 180 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| total static weight capacity | 454 kg | |
|---|---|---|
| per-seat static weight capacity | 227 kg | |
| seat foam density | 34 kg/m³ | |
| seat cushion thickness | 120 mm | |
| backrest cushion thickness | 150 mm | |
| back fill rebound rate | 60% | |
| foam compression set resistance | 30000 cycles | |
| net product weight | 45 kg | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| seat and back upholstery | Light off-white woven polyester fabric, 300g/m² weight, matte finish | |
|---|---|---|
| outer arm panel upholstery | Dusty blue woven polyester fabric, matching fabric weight to seat panels | |
| edge trim | Thin silver metallic PVC piping along all upholstery seam edges | |
| seat cushion fill | High-density polyurethane foam wrapped in 20mm soft polyester fiber | |
| backrest fill | Blended high-density foam and polyester fiber fill for upright support | |
| support legs | 1.2mm thick black powder-coated steel, angled geometric profile | |
| internal frame | 25mm thick kiln-dried solid hardwood and plywood structural frame | |
| seat support system | 80mm wide elastic webbing spaced 80mm apart across seat base | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| seating configuration | Fixed two-position integrated seating with non-removable fixed backrest | |
|---|---|---|
| armrest support | Fully padded structural block armrests supporting lateral body weight | |
| leg attachment | Threaded metal leg inserts for tool-free leg installation during assembly | |
| floor protection | Plastic floor glides installed at leg bases to prevent hard floor scratching | |
| stationary use design | No recline, fold, or convertible mechanism, for fixed upright seating | |
| seam construction | 8 stitches per 30mm seam pitch with reinforced edge piping | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| small living room seating | Suitable for compact residential living rooms as primary two-person seating | |
|---|---|---|
| office reception area seating | Appropriate for modern office reception or waiting areas for guest use | |
| bedroom lounge seating | Fits as secondary seating in large bedrooms or studio apartments | |
| small apartment open plan seating | Ideal for open-plan studio apartments as space-efficient main seating | |
| recommended surrounding clearance | Minimum 300mm clearance behind sofa for cleaning and air circulation |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| upholstered furniture strength and durability | EN 12520:2015 | |
|---|---|---|
| upholstered furniture stability testing | EN 1022:2005 | |
| furniture foam emission requirement | EN 13722:2004 |
北美市场采购验货参考 * ANSI/BIFMA 标准
美国及加拿大家具标准
| lounge seating static load test | ANSI/BIFMA X2020 | |
|---|---|---|
| lounge seating durability cycle test | ANSI/BIFMA X2020 |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| upholstered furniture safety standard | GB 28007 | |
|---|---|---|
| furniture foam flame retardancy | GB 20286 | |
| furniture mechanical performance for seating | GB/T 3324 | |
| fabric color fastness requirement | GB/T 23344 |
本产品须满足以下技术参数要求: 1. upholstered furniture safety standard:GB 28007; 2. furniture foam flame retardancy:GB 20286; 3. furniture mechanical performance for seating:GB/T 3324; 4. fabric color fastness requirement:GB/T 23344; 最终交付参数、检测报告和验收标准以双方采购合同为准。
