基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1400 × 800 × 450 mm | |
|---|---|---|
| Sintered stone top thickness | 15 mm | |
| Pedestal base width | 700 mm | |
| Pedestal base depth | 300 mm | |
| Pedestal base height | 435 mm | |
| Decorative inlay length | 120 mm | |
| Floor clearance under base | 15 mm | |
| Top surface overhang (long sides) | 350 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Net product weight | 60 kg | |
|---|---|---|
| Static distributed top load | 70 kg | |
| Surface heat resistance | 180 °C | |
| Surface scratch resistance (Mohs hardness) | 6 | |
| Stain resistance rating | Grade 5 | |
| Anti-slip pad static friction coefficient | 0.6 | |
| Metal base anti-rust coating thickness | 80 μm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Table top | 15mm matte sintered stone, polished smooth edge | |
|---|---|---|
| Pedestal base core | High density MDF with dark grey matte lacquer finish | |
| Decorative inlays | Brushed 304 stainless steel vertical strips | |
| Connection hardware | Zinc-plated steel M8 assembly bolts | |
| Floor protection pads | 5mm thick non-slip EVA rubber pads | |
| Base surface coating | Matte polyurethane lacquer, scratch-resistant finish | |
| Underside support frame | 1.2mm thick carbon steel cross bracing | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Surface use function | Flat level surface for placing drinks, decor, books and small lounge items | |
|---|---|---|
| Assembly mechanism | Detachable top and pedestal connected via bolted joints | |
| Floor protection function | EVA pads under base isolate hard contact to prevent floor scratches | |
| Stability design | Centered solid pedestal base eliminates wobble on level floors | |
| Cleaning function | Non-porous sintered top allows wipe-clean with damp cloth, no sealant required | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Residential living room | Positioned in front of 3-seat sofa between armchairs for lounge serving use | |
|---|---|---|
| Lounge reception area | Used in small office reception spaces for holding guest refreshments and decor | |
| Model home display | Featured in modern minimalist or Italian luxury show home settings | |
| Small apartment living space | 1400mm length fits compact living rooms without blocking walkways | |
| Recommended pairing | Matched with dark leather or fabric sofa sets in dark grey/black finishes |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 15372:2008 | Domestic furniture strength and durability requirements for tables | |
|---|---|---|
| EN 13722:2004 | Furniture surface resistance to cold liquids for daily use performance |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to base structure | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard/MDF requirements for furniture grade panels used in base | |
| GB 18584-2001 | Indoor decoration material furniture formaldehyde emission limit for panel components | |
| GB/T 17657-2013 | Test methods for surface wear and heat resistance of furniture surfaces |
本产品须满足以下技术参数要求: 1. GB/T 3324-2017:General technical requirements for wooden furniture, applicable to base structure; 2. GB/T 4897.3-2015:Particleboard/MDF requirements for furniture grade panels used in base; 3. GB 18584-2001:Indoor decoration material furniture formaldehyde emission limit for panel components; 4. GB/T 17657-2013:Test methods for surface wear and heat resistance of furniture surfaces; 最终交付参数、检测报告和验收标准以双方采购合同为准。
