基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2400 × 2400 × 760 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Seating capacity | 12 diners with one full place setting per position | |
|---|---|---|
| Distributed tabletop load capacity | 120 kg static load for food, tableware, and lazy susan use | |
| Lazy susan center load | 30 kg maximum evenly distributed rotating load | |
| Net weight of complete table | 220 kg | |
| Recommended floor load | 3.0 kPa local concentrated-floor allowance for the complete set | |
| Rotational service target | 50,000 lazy-susan revolutions with a 30 kg balanced load | |
| Chair frame durability target | 100,000 cyclic back-rest cycles at 135 kg occupant load | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Fixed tabletop | White engineered-stone or marble-look surface with gray veining, 20 mm nominal slab thickness | |
|---|---|---|
| Edge and rotating rim | Walnut-color wood veneer or solid wood edge band with rounded profile | |
| Central rotating panel | Walnut-figured wood veneer disc, 18 mm nominal panel thickness | |
| Pedestal base | Curved cabinet-form wood base with walnut veneer exterior and stiffening inner substrate | |
| Chair frame | Stained walnut-color hardwood or bent laminated wood frame with four tapered legs and continuous arms | |
| Chair upholstery | Cream-white fabric or leather-look upholstery over padded seat and back panels |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Lazy susan rotation | 1100 mm circular center rotates 360 degrees on a concealed ring bearing to share dishes from all seats | |
|---|---|---|
| Fixed dining zone | Outer 650 mm-wide stationary ring provides twelve individual place-setting and elbow zones | |
| Seating arrangement | Twelve armchairs arrange radially around the pedestal with a 628 mm place-setting pitch | |
| Pedestal access | Curved drum base supports the top centrally and leaves perimeter leg positions for twelve diners, without individual corner legs |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Package count | 6 packages: one tabletop crate, one pedestal crate, one lazy-susan crate, and three chair cartons | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| VIP private dining room | Suited to upscale hotel, club, corporate reception, and restaurant private rooms requiring twelve served seats and shared-dish rotation. | |
|---|---|---|
| Formal banquet or hospitality suite | The wood-and-stone appearance and cream upholstered armchairs support executive lunches, family banquets, and hosted negotiations rather than casual cafeteria use. |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
本产品须满足以下技术参数要求: 1. 技术标准与检测报告由供应商在投标或采购确认阶段提供; 最终交付参数、检测报告和验收标准以双方采购合同为准。
