基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 1800 × 1800 × 760 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Distributed tabletop load capacity | 120 kg for dinnerware, shared dishes, and decorative items | |
|---|---|---|
| Concentrated rotating disc load | 30 kg centered on the bearing without binding | |
| Table static base stability | withstands 80 kg lateral edge force without overturning on level flooring | |
| Per-chair occupant load | 135 kg static seated weight per armchair | |
| Chair frame cyclic seating durability | 100,000 front-edge load cycles without loose joints | |
| Connector joint pull-out resistance | 800 N per major wood-to-wood chair joint | |
| Stone surface impact resistance | 1 kg steel ball dropped from 150 mm without through-crack | |
| Floor loading footprint | 2.65 kPa total set load with chairs placed around the table | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop surface | 12 mm light engineered-stone face bonded to an 18 mm moisture-resistant substrate for flat rigid support | |
|---|---|---|
| Table edge | 60 mm walnut-toned solid wood veneered MDF rim with eased profile and sealed finish | |
| Rotating disc | 12 mm engineered-stone face with dark wood rim and underside steel bearing ring | |
| Pedestal cabinet | 18 mm walnut-veneer wood-based panels with matte clear lacquer and enclosed circular apron | |
| Support frame | four 60 x 60 mm hardwood-toned vertical posts connected to a 40 x 60 mm lower perimeter rail | |
| Bottom plinth | 40 mm laminated wood ring with dark protective finish and floor glide pads |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
|---|---|---|
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Recommended Matching Desk Size | 2.4 m executive desk | |
|---|---|---|
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
本产品须满足以下技术参数要求: 1. 技术标准与检测报告由供应商在投标或采购确认阶段提供; 最终交付参数、检测报告和验收标准以双方采购合同为准。
