基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 2400 × 2400 × 760 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Table static load capacity | 600 kg | |
|---|---|---|
| Seating capacity | 10 diners | |
| Tabletop uniformly distributed load | 600 kg | |
| Central lazy Susan rotating load | 80 kg | |
| Per-chair static seat load | 160 kg | |
| Chair frame cyclic seating endurance | 100000 cycles | |
| Lazy Susan rotation cycles | 50000 cycles | |
| Table stability lateral resistance | 150 N applied at table edge | |
| Top surface impact resistance | 1 kg steel ball dropped from 150 mm | |
| Wood moisture content | 10 percent |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Outer tabletop | 25 mm engineered-stone substrate with light marble-veneer face and timber edge band | |
|---|---|---|
| Central lazy Susan | 25 mm segmented walnut-toned wood veneer on moisture-resistant substrate | |
| Rotating mechanism | Concealed steel ball-bearing turntable with quiet polymer race | |
| Table edge and rim | Solid walnut-toned hardwood border with rounded profile | |
| Apron and pedestal | Wood-composite panels with walnut-veneer outer face and solid-wood corner posts | |
| Base support structure | Kiln-dried hardwood inner frame joined to steel pedestal plate |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Lazy Susan rotation | 360 degree manual rotation on a concealed bearing, serving all ten seating positions | |
|---|---|---|
| Place setting layout | Ten evenly spaced settings at 754 mm arc spacing, including plate, bowl, cup, and chopstick positions | |
| Chair tuck-in | Arms slide under the table rim with 100 mm nominal insertion depth | |
| Seating access | Open-frame arm openings permit side entry without rotating the chair |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Private hotel dining room | Fits ten guests in a 4200 mm square room for hosted banquets and round-table service. | |
|---|---|---|
| Chinese restaurant VIP room | Supports shared dishes on the 1100 mm rotating tray with full place settings around the rim. |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
本产品须满足以下技术参数要求: 1. 技术标准与检测报告由供应商在投标或采购确认阶段提供; 最终交付参数、检测报告和验收标准以双方采购合同为准。
