High-Back Ergonomic Mesh Office Chair with Adjustable Headrest Specifications

OFC-MSH-HB-001

代码:C5CTU3V1
获取供应商报价
2026-08-11 17:38人气: 53
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

OFC-MSH-HB-001

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions660 x 660 x 1220 mm
Finished Seat Cushion Thickness90 mm
Backrest Padding Thickness70 mm
Lumbar Support Zone Height240 mm
Clear Width Between Armrests540 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Recommended user weight capacity136 kg
Net product weight16 kg
Gas lift height adjustment stroke100 mm
Caster rolling durability rating40000 cycles
Recommended daily usage duration8 hours
Warranty period3 years
Available color options1
Seat Foam Density / Rebound Reference45 kg/m³ / 65%
Back Foam Density Reference38 kg/m³
Upholstery Thickness / Abrasion Reference1.4 mm / 50000 cycles
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Backrest upholsteryBreathable black polyester mesh
Seat cushion core40 mm high-density molded polyurethane foam
Seat upholsteryBlack wear-resistant woven fabric
Frame componentsInjection-molded black glass-fiber reinforced nylon
Five-star baseBlack nylon five-prong base
Gas lift cylinderChromed steel Class 3 gas lift
Casters50 mm diameter black polyurethane twin-wheel casters
Tilt mechanism2.5 mm thick steel plate synchro-tilt mechanism
Seam stitch pitch8 stitches per inch
Headrest padding20 mm thick polyurethane foam padded mesh headrest
Seat Internal Support Board Thickness14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness14 mm bent plywood/composite reinforced frame
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Seat height adjustmentPneumatic height adjustment via right-hand lever, 100 mm stroke, lock at any position
Swivel function360-degree unrestricted rotation around central gas lift axis
Backrest tilt functionBackrest tilts 15 degrees rearward with single-position upright lock
Headrest adjustmentUp/down height adjustment and angle tilt for neck support
Mobility functionSmooth rolling on hard floors and low-pile carpet via dual-wheel PU casters
Lumbar supportBuilt-in curved lumbar support zone integrated into lower mesh back
Armrest supportFixed curved loop armrests provide forearm support during typing
Weight balance tension controlTilt tension adjustment knob under seat tunes recline resistance to user weight
Recline Angle / Lock Reference125° with 3suggested lock positions
Tilt Tension User-weight RangeReference adjustment coverage 120 kg
Rotation / Mobility Configuration360° swivel with 5-caster multidirectional movement
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Carton Dimensions850× 420× 720 mm
Reference Packaged Gross Weight23 kg/set
Reference Carton Volume0.26 m³/set
Indicative 20GP Loading135 sets at 85% space utilization
Indicative 40HQ Loading320 sets at 85% space utilization
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open office workstationsSuitable for 8-hour daily task use at standard height desks, with breathable mesh for all-day comfort
Home office setupsCompact 660 mm footprint fits small home workspaces without occupying excess floor area
Conference room seatingNeutral black finish and professional design suit formal meeting spaces and boardrooms
Coworking spacesDurable construction and adjustable height fit diverse user populations in shared work environments
Training room applicationsRolling casters and swivel function allow easy repositioning during group training sessions
Recommended Matching Desk Size2.4 m executive desk
Reference Daily Use Duration8 hours/day; confirm by ergonomic testing
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

Office chair safety referenceEN 1335:2020
Caster durability referenceEN 12529:2021
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

Task chair durability referenceANSI/BIFMA X2017
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

Static load test referenceGB/T 10357.3
Flammability referenceGB 20286
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. Static load test reference:GB/T 10357.3;
2. Flammability reference:GB 20286;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · OFC-MSH-HB-001

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · OFC-MSH-HB-001

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · OFC-MSH-HB-001打开导出工具

页面快速操作

发布采购询价

产品描述

The High-Back Ergonomic Mesh Office Chair with Adjustable Headrest, model OFC-MSH-HB-001, is an unbranded ergonomic seating solution designed for sustained daily use across professional and personal workspaces. It features a streamlined, professional silhouette with a tall contoured mesh backrest, integrated curved lumbar support zone, fixed looped armrests, and a matching adjustable headrest, finished entirely in neutral black to complement a broad range of interior design schemes. The chair’s compact footprint balances generous functional clearances between armrests and padded support surfaces, with balanced proportions that avoid visual bulk in both open and enclosed spaces. Its construction balances durability and seated comfort: the backrest uses breathable black polyester mesh stretched over an injection-molded, glass-fiber reinforced nylon frame for consistent structural support, while the seat pairs a high-density molded polyurethane foam core with wear-resistant black woven fabric upholstery for resilient, long-lasting cushioning. The base is a sturdy five-prong black nylon structure fitted with smooth twin-wheel polyurethane casters, supported by a chromed steel Class 3 gas lift and steel plate synchro-tilt mechanism for reliable, long-term operation. Core functional features support flexible, comfortable use across work tasks: a right-hand lever controls pneumatic seat height adjustment with a full travel stroke that locks at any user-preferred position, while 360-degree swivel rotation enables easy access to surrounding work surfaces. The backrest tilts 15 degrees rearward with a single-position upright lock for focused work, and the attached headrest adjusts both vertically and in tilt angle to deliver customized neck support. The fixed curved armrests position forearms comfortably during typing, and the dual-wheel casters roll smoothly across hard floors and low-pile carpet for easy repositioning. This chair is well suited for a wide range of spaces: it performs reliably for 8-hour daily task use at standard-height open office workstations, fits neatly into compact home office setups with its space-efficient footprint, presents a polished, professional look for conference rooms and boardrooms, accommodates diverse users in shared coworking environments, and supports quick layout changes during training sessions thanks to its mobile, swiveling design. It pairs well with standard executive desks for cohesive work area setups. For procurement planning, note the chair ships in two cartons per set, with a straightforward assembly process for on-site setup. It carries a 3-year warranty, supports a maximum recommended user weight aligned with standard commercial seating requirements, and is offered in a single black color option for consistent, uniform furnishing across large spaces.
