Mid-Back Mesh Swivel Office Task Chair Specifications

OFCH-MESH-064

代码:F0YEQXV1
获取供应商报价
2026-08-11 15:19人气: 37
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

OFCH-MESH-064

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall dimensions640 x 640 x 1060 mm
Finished Seat Cushion Thickness90 mm
Backrest Padding Thickness70 mm
Lumbar Support Zone Height240 mm
Clear Width Between Armrests540 mm
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Product net weight12 kg
Maximum static user weight capacity120 kg
Gas lift stroke length100 mm
Seat dynamic load rating95 kg
Caster rolling durability cycles40000
Backrest tilt lock angle12 degrees
Warranty period for structural components3 years
Seat Foam Density / Rebound Reference45 kg/m³ / 65%
Back Foam Density Reference38 kg/m³
Upholstery Thickness / Abrasion Reference1.4 mm / 50000 cycles
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Backrest central supportTensioned breathable polyester mesh
Backrest outer frameReinforced polypropylene plastic
Seat cushion core45kg/m³ density high-resilience polyurethane foam
Seat upholsteryWear-resistant polyester fabric
ArmrestsFixed hard polypropylene with flat padded top
Height adjustment mechanismClass 3 carbon steel gas lift
Five-star baseGlass-fiber reinforced nylon, 2.5mm wall thickness
Casters50mm diameter polyurethane rolling wheels
Tilt chassis2.5mm thick stamped steel plate
Seat seam stitch pitch8 stitches per 30mm
Seat Internal Support Board Thickness14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness14 mm bent plywood/composite reinforced frame
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Seat height adjustmentPneumatic 100mm travel adjusted via right-side under-seat lever, locks at any position within range
360-degree swivel rotationFull rotation around central gas lift axis for multi-directional access
Backrest tilt functionSynchronized 12-degree backward tilt with tension adjustment, no multi-position lock visible
Fixed arm supportRigid non-adjustable armrests positioned 190mm above seat surface for forearm support
Smooth rolling mobility5 dual-wheel casters for movement on hard floors and low-pile carpet
Lumbar supportContoured lower back frame provides static lumbar contact without adjustable pad
Seat waterfall edgeRounded front seat edge reduces thigh pressure during extended sitting
Recline Angle / Lock Reference125° with 3suggested lock positions
Tilt Tension User-weight RangeReference adjustment coverage 120 kg
Rotation / Mobility Configuration360° swivel with 5-caster multidirectional movement
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Carton Dimensions850× 420× 720 mm
Reference Packaged Gross Weight23 kg/set
Reference Carton Volume0.26 m³/set
Indicative 20GP Loading135 sets at 85% space utilization
Indicative 40HQ Loading320 sets at 85% space utilization
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Open-plan office workstationsDurable ergonomic support for 8-hour daily employee use in general office environments
Home office workspacesCompact footprint fits small home desk setups for remote work and study
Conference and meeting roomsStackable and lightweight design suitable for temporary meeting room seating
Training room facilitiesWheeled base allows easy reconfiguration for classroom or training layouts
Small business reception areasNeutral black finish complements standard office reception decor
Recommended Matching Desk Size2.4 m executive desk
Reference Daily Use Duration8 hours/day; confirm by ergonomic testing
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

Office furniture office chairs safety and strengthEN 1335:2018
Office furniture office chairs dimensional stabilityEN 1335:2020
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

Office chairs general purpose testsANSI/BIFMA X2017
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

Office chair strength and durabilityGB/T 10357.3
Formaldehyde emission limitsGB 18584
Office chair safety requirementsGB 28007
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. Office chair strength and durability:GB/T 10357.3;
2. Formaldehyde emission limits:GB 18584;
3. Office chair safety requirements:GB 28007;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · OFCH-MESH-064

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · OFCH-MESH-064

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · OFCH-MESH-064打开导出工具

页面快速操作

发布采购询价

产品描述

The unbranded Mid-Back Mesh Swivel Office Task Chair, model OFCH-MESH-064, presents a streamlined, functional silhouette designed for versatile workplace and home use. It features a neutral black finish that blends seamlessly with standard commercial and residential decor, with a compact 640 x 640 mm footprint that fits neatly under work surfaces without excess visual bulk. Its mid-height back is framed in reinforced polypropylene, with a tensioned breathable polyester mesh center that curves to form a static lumbar support zone, paired with a fabric-upholstered seat finished with a rounded waterfall front edge. Fixed hard polypropylene armrests sit 190mm above the seat surface, topped with flat padding, and the chair rests on a five-star base fitted with dual-wheel casters for unobtrusive, stable support. Durable, purpose-built materials form the chair’s core structure. The 90mm thick seat cushion uses 45kg/m³ density high-resilience polyurethane foam wrapped in wear-resistant polyester fabric, while the 70mm thick back section relies on flexible mesh for constant air circulation. The frame uses reinforced plastic, paired with a Class 3 carbon steel gas lift, a 2.5mm thick stamped steel tilt chassis, and a glass-fiber reinforced nylon five-star base with 2.5mm wall thickness. It rolls on 50mm diameter polyurethane casters, with all structural components covered by a 3-year warranty. The chair supports a maximum static user weight of 120 kg, with a 95 kg seat dynamic load rating, and casters rated for 40,000 rolling cycles. Key practical functions support daily seated use: pneumatic seat height adjustment delivers 100mm of travel via a right-side under-seat lever, locking at any position across its range, while full 360-degree swivel allows easy multi-directional access to desk surfaces. The backrest offers a synchronized 12-degree backward tilt with adjustable tension, and the casters move smoothly across hard floors and low-pile carpet. The contoured lower back frame delivers consistent static lumbar contact, and the waterfall seat edge reduces thigh pressure during extended sitting sessions. This chair is suited for a range of spaces: open-plan office workstations for 8-hour daily employee use, compact home office setups for remote work and study, conference and meeting rooms for temporary seating, training facilities where easy reconfiguration is needed, and small business reception areas. It pairs optimally with desks up to 2.4m in width. For procurement, note each unit ships in 2 cartons, requires 40 minutes of assembly per set, and 135 sets fit in a 20GP container at 85% space utilization, with a packaged gross weight of 23 kg per set.
