PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	660 × 660 × 1055 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Recommended user weight capacity	150 kg
Net product weight	12 kg
Gas lift height adjustment stroke	100 mm
Seat foam density	45 kg/m³
Back mesh tensile strength	180 N/5cm
Chair swivel rotation range	360 degrees
Seam stitch pitch	8 mm
Caster rolling durability	40000 cycles
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Backrest upholstery	Breathable blue woven polyester mesh
Backrest frame	Light grey reinforced polypropylene
Seat cushion upholstery	Dark grey woven fabric
Seat cushion core	High-density molded polyurethane foam
Armrests	Fixed-height flip-up light grey polypropylene
Five-star base	White reinforced nylon
Gas lift	Black powder-coated steel
Casters	Black dual-wheel polyurethane
Seat mechanism	Black steel tilt-lock chassis
Internal seat support plate	1.8mm thick cold-rolled steel
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Seat height adjustment	Pneumatic height adjustment via side lever
Backrest tilt function	Synchro-tilt mechanism with tension adjustment
Swivel function	360-degree frictionless swivel
Flip-up armrests	90-degree upward folding armrests
Lumbar support	Integrated contoured mesh lumbar zone
Caster mobility	Dual-wheel swivel casters on all 5 base points
Tilt tension control	Rotary tension knob under seat
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Open-plan office workstations	Mid-back ergonomic support for 8 hour daily task work at standard desks
Home office spaces	Compact footprint fits small residential work areas without excess bulk
Conference meeting rooms	360-degree swivel and neutral design suited for collaborative meeting spaces
Shared hot-desking areas	Durable construction and flip-up armrests accommodate wide range of user heights
Study and student desks	Adjustable height fits growing users and standard study desk dimensions
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

Office furniture safety requirements	EN 1335:2020
Office chair caster performance	EN 12528:2000
Furniture fire resistance	EN 1021:2014

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

Office chair general purpose standard	ANSI/BIFMA X2017
Office chair durability testing	ANSI/BIFMA X2017Clause 11
Office chair stability testing	ANSI/BIFMA X2017Clause 7

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

Office chair structural safety	GB/T 10357.2
Office chair strength and durability	GB/T 10357.3
Furniture hazardous material limits	GB 18584

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. Office chair structural safety：GB/T 10357.2；
2. Office chair strength and durability：GB/T 10357.3；
3. Furniture hazardous material limits：GB 18584；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · OFC-MESH-660BL

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · OFC-MESH-660BL

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · OFC-MESH-660BL打开导出工具

页面快速操作

发布采购询价

产品描述

The Ergonomic Mid-Back Mesh Swivel Office Chair, model OFC-MESH-660BL, is an unbranded office task chair designed for versatile daily use across work and study environments. Visually, it features a breathable blue woven polyester mesh backrest set in a light grey reinforced polypropylene frame, paired with a dark grey woven fabric seat cushion, white reinforced nylon five-star base, and black dual-wheel polyurethane casters for a clean, neutral aesthetic that blends with most interior design schemes. The chair’s overall dimensions are 660 x 660 x 1055 mm, with a 540 mm clear width between armrests, creating a streamlined, compact silhouette that avoids unnecessary bulk. Its integrated contoured mesh lumbar support sits across a 240 mm zone, paired with a 70 mm thick padded backrest and 90 mm thick seat cushion filled with 45 kg/m³ high-density molded polyurethane foam, delivering consistent, balanced support for extended seated sessions. All structural hardware is constructed from steel, with a black powder-coated steel gas lift and black steel tilt-lock chassis for long-term durability. For flexible function, the chair offers 360-degree frictionless swivel rotation, pneumatic seat height adjustment via a side lever with 100 mm of adjustment travel, and a synchro-tilt backrest mechanism with an under-seat rotary tension control knob for personalized recline resistance. The fixed-height light grey polypropylene armrests fold upward 90 degrees to allow the chair to slide fully under desk surfaces when not in use, while dual-wheel swivel casters on all five base points enable smooth, quiet movement across hard and soft flooring. The back mesh has a tensile strength of 180 N/5cm, with 8 mm seam stitch pitch, and supports a maximum user weight of 150 kg with a net product weight of 12 kg. This chair is well-suited for open-plan office workstations supporting 8 hours of daily task work at standard desks, compact home office spaces, collaborative conference meeting rooms, shared hot-desking areas serving diverse user groups, and student or home study desks. It is ideally paired with a 2.4 m executive desk for proportional alignment. For procurement, note that each unit ships in 2 cartons with a packaged gross weight of 23 kg, 0.26 m³ total carton volume, and requires 40 minutes of assembly per set. A 20GP container can hold 135 sets at 85% space utilization, making it a practical choice for bulk and single-unit purchasing alike.

Ergonomic Mid-Back Mesh Swivel Office Chair Specifications
