Name: High-Back Ergonomic Mesh Office Chair with Adjustable Headrest
Brand: YUXIANG
SKU: XV92CU

纠错时间

修改字段

原参数

修改后参数

说明 / 状态

暂无参数纠错记录，发现错误可点击行末旗标提交

PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	635 × 680 × 1215 mm
Seat width	505 mm
Seat depth	465 mm
Seat height range (floor to seat)	525 mm
Backrest height (seat to top of back)	570 mm
Armrest height above seat	200 mm
Headrest height adjustment range	60 mm
Five-star base wheel span	680 mm
Headrest width	315 mm
Backrest width	430 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Recommended user weight capacity	181 kg
Net chair weight	20 kg
Static base load rating	1136 kg
Gas lift cycle durability	120000 cycles
Seat foam density	55 kg/m³
Mesh upholstery abrasion rating	50000 Martindale double rubs
Seam stitch pitch	8 stitches per 30mm
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Backrest upholstery	High-tensile breathable polyester mesh
Seat cushion core	High-resilience cold-cure polyurethane foam
Seat surface upholstery	Breathable woven mesh fabric
Chair internal frame	Reinforced 3mm thick steel inner frame
Five-star base	Glass-filled nylon with 2.5mm wall thickness
Gas lift cylinder	Steel SGS Class 4 pneumatic cylinder
Tilt mechanism chassis	2.5mm thick stamped steel plate
Armrests	Reinforced PA plastic padded arm pads
Casters	60mm diameter dual-wheel PU silent casters
Headrest	Curved mesh-padded PA frame
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Seat height adjustment	Pneumatic gas lift adjusts 85mm to match varied desk heights
Headrest adjustment	60mm vertical lift to support neck posture for tall users
Armrest adjustment	70mm vertical height adjustment to align with desk surfaces
Backrest recline	135-degree tilt with tension control for relaxed working postures
Swivel function	360-degree full rotation for multi-directional desk access
Mobility	Smooth rolling on all floor types via dual-wheel PU casters
Lumbar support	Integrated contoured lumbar zone aligned to natural lower back curve
Waterfall seat edge	Contoured front seat edge reduces leg pressure for extended sitting
Maximum back recline angle	135 degrees
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Private office workstation use	Ideal for 8 hour daily seated desk work for administrative staff
Home office computer desk setup	Suitable for remote workers requiring lumbar and neck support
Open-plan task workstations	Durable construction for shared team desks in co-working spaces
Conference room meeting seating	Swivel and tilt function supports flexible meeting postures
Height-adjustable desk pairing	85mm seat height adjustment matches sit-stand desk ergonomics
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

Office furniture office chair safety	EN 1335:2020
Office chair strength/durability	EN 1335:2018
Office chair stability	EN 1335:2009

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

Office chair general purpose standard	ANSI/BIFMA X2017

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

Office chair stability standard	GB/T 10357.2
Office chair strength/durability	GB/T 10357.3
Upholstered furniture safety	GB 20400

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. Office chair stability standard：GB/T 10357.2；
2. Office chair strength/durability：GB/T 10357.3；
3. Upholstered furniture safety：GB 20400；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · EMOC-635-BLK

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · EMOC-635-BLK

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · EMOC-635-BLK打开导出工具

页面快速操作

发布采购询价

产品描述

The YUXIANG EMOC-635-BLK High-Back Ergonomic Mesh Office Chair delivers a balanced blend of structured support and streamlined, professional aesthetic suited to extended seated use. Its visual profile features a tall, contoured high-back form finished in uniform black, with a structured upright layout that pairs a breathable mesh backrest, integrated curved lumbar zone, adjustable padded armrests, and height-adjustable headrest, all mounted to a wide five-star base with smooth rolling casters. The chair’s construction prioritizes long-term durability and consistent comfort: the backrest is upholstered in high-tensile breathable polyester mesh, while the seat uses a high-resilience cold-cure polyurethane foam core surfaced with breathable woven mesh fabric. The internal structure relies on a reinforced 3mm thick steel inner frame, paired with a glass-filled nylon five-star base, 2.5mm thick stamped steel tilt chassis, SGS Class 4 steel pneumatic gas lift, reinforced PA plastic padded armrests, and 60mm dual-wheel PU silent casters. Functional design is tailored to flexible working needs: pneumatic seat height adjustment covers 85mm of travel to align with varied desk heights, the headrest offers 60mm of vertical lift to support neck posture for taller users, and armrests adjust 70mm vertically to match desk surface heights. The backrest reclines to 135 degrees with adjustable tension control for relaxed postures, 360-degree swivel enables easy multi-directional access to desk surfaces, and the dual-wheel casters roll smoothly across all floor types. The integrated contoured lumbar zone aligns with the natural curve of the lower back to reduce strain during long work sessions. This chair fits a wide range of commercial and residential spaces, including private office workstations for administrative staff completing 8 hours of daily seated work, home office setups for remote workers seeking consistent neck and lumbar support, open-plan and co-working shared task stations, and conference room seating for flexible meeting postures. It also pairs seamlessly with height-adjustable sit-stand desks, and is recommended for use with a 2.4m executive desk. For procurement planning, note that each unit ships in two cartons, with a reference assembly time of 40 minutes per set, and a static base load rating that supports a recommended user weight capacity of 181kg. The mesh upholstery carries a 50000 Martindale double rub abrasion rating, seat foam has a density of 55kg/m³, and the gas lift is rated for 120000 cycles of use, supporting long-term deployment in high-traffic shared environments. At 85% space utilization, 135 sets fit in a 20GP shipping container for bulk order planning.

High-Back Ergonomic Mesh Office Chair with Adjustable Headrest Specifications
