PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	620 × 630 × 1000 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Recommended user weight capacity	120 kg
Net weight	13.5 kg
Static base verification load	500 kg
Seat foam density	45 kg/m3
Back mesh tensile verification	800 N in warp and weft
Caster rolling durability	100000 cycles
Gas-lift cycles	100000 height-adjustment cycles
Seating capacity	1 person
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Backrest	Grey flexible woven mesh over a matching rigid outer frame
Lumbar support	Darker integrated mesh lumbar zone with shaped lateral cutouts
Seat cushion	70 mm molded polyurethane foam with green woven upholstery
Seat shell	Black molded polymer load-bearing shell under the cushion
Armrests	Light grey molded fixed T-arms with rounded polymer pads
Gas lift and base	Chrome-plated steel five-star base with polished central gas-lift tube

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Height adjustment	Pneumatic seat-height lift with 100 mm travel operated by the visible right-side lever.
Tilt movement	Synchronized seat-and-back recline with 12-degree rearward travel and weight-activated tension.
Tilt lock	Single-position upright lockout controlled through the under-seat mechanism; exact lever sequence requires BOM confirmation.
Mobility	Five dual-wheel casters provide rolling movement on hard floors and low-pile carpet.

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Workstation use	Suited to open-plan desks, bench workstations and private offices where a compact 620 mm-wide chair is required.
User profile	Designed for single users needing breathable mesh back support, padded seating and mobility during daily computer work.

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

该市场暂无标准数据。

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

该市场暂无标准数据。

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. 技术标准与检测报告由供应商在投标或采购确认阶段提供；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · OC-MESH-MB-GRN-5P

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · OC-MESH-MB-GRN-5P

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · OC-MESH-MB-GRN-5P打开导出工具

页面快速操作

发布采购询价

产品描述

The Mesh Mid-Back Swivel Task Chair with Green Upholstered Seat is an unbranded office chair designed for daily computer-based work. Its appearance balances a neutral grey back with a green seat, creating a clean contemporary look that fits both functional work areas and more styled interior schemes. The chair has a mid-height mesh backrest supported by a matching rigid outer frame, with a darker integrated lumbar zone and shaped lateral cutouts. Below, the green woven upholstered seat is paired with light grey fixed T-armrests, rounded polymer pads, a polished chrome-plated steel five-star base, and black twin-wheel casters. Overall dimensions are 620 x 630 x 1000 mm, with a 540 mm clear width between the armrests, giving the chair a compact footprint suitable for individual workstation settings. Construction combines breathable and supportive materials. The backrest uses flexible woven mesh, while the seat features molded polyurethane foam beneath green woven upholstery. The finished cushion thickness is 90 mm, with 70 mm molded foam specified in the seat construction and 70 mm of backrest padding thickness. A black molded polymer load-bearing shell sits under the cushion, and molded fixed armrests provide defined arm support. The chrome-plated steel five-star base, central polished gas-lift tube, and dual-wheel casters complete the structure. The chair is intended for users up to 120 kg, has a net weight of 13.5 kg, and uses a 45 kg/m3 seat foam density. Practical operation centers on swivel mobility, pneumatic height adjustment, and synchronized recline. A visible right-side lever controls the gas-lift seat-height adjustment, which offers 100 mm of travel. The synchronized seat-and-back tilt provides 12 degrees of rearward movement with weight-activated tension, while an under-seat mechanism offers a single-position upright lockout. Five dual-wheel casters support rolling on hard floors and low-pile carpet, making the chair appropriate for open-plan desks, bench workstations, and private offices where a 620 mm-wide task chair is required. It is best suited to single users seeking breathable back support, a padded seat, fixed armrests, and mobility during routine desk work. Procurement teams should note that each set ships in two cartons, with packaged gross weight of 23 kg and reference assembly time of 40 minutes. The reference carton dimensions are 850 x 420 x 720 mm and reference carton volume is 0.26 m3 per set. For bulk planning, the indicative 20GP loading is 135 sets at 85 percent space utilization. Buyers specifying large projects should also review the exact tilt-lock lever sequence against the final bill of materials, particularly if consistent user instruction or standardized assembly documentation is required.

Mesh Mid-Back Swivel Task Chair with Green Upholstered Seat Specifications
