PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	670 × 680 × 1290 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Recommended user weight	135 kg
Seat static-load verification target	102 kg
Back-rest static-load verification target	68 kg force
Caster rolling durability target	100000 cycles
Gas-lift cycles	200000 height-adjustment cycles
Fabric abrasion acceptance	50000 Martindale cycles
Foam density	45 kg/m3 molded seat foam
Foam rebound	40 percent
Net chair weight	17.5 kg
Color options	1 visible two-tone colorway

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Backrest support	Light gray molded polypropylene outer frame with flexible light-gray mesh suspension
Seat cushion	Red woven textile over high-resilience molded foam
Headrest	Dark gray padded cushion with matching upholstered face and rigid support block
Armrests	Fixed gray polypropylene T-arms with padded horizontal contact pads
Seat mechanism	Black steel tilt mechanism with visible operating lever and tension knob
Gas lift	Chrome-plated steel telescopic gas lift with black plastic shroud

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Height adjustment	Pneumatic seat-height lift through 80 mm stroke using the right-side lever under the seat
Recline control	Synchro tilt allows seat and back movement to 115 degrees, with lockable upright and reclined positions
Tension adjustment	Rotary tension knob under the seat modifies backward resistance for user weight
Swivel and mobility	360-degree swivel seat on five twin-wheel casters for carpet and hard-floor movement

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Primary workplace	Executive workstations, open-plan offices, and home offices requiring head, lumbar, and arm support
Recommended configuration	Use with 720 to 760 mm high desks on hard floors or low-pile carpet

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

该市场暂无标准数据。

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

该市场暂无标准数据。

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. 技术标准与检测报告由供应商在投标或采购确认阶段提供；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · ERG-MESH-HB-RED-01

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · ERG-MESH-HB-RED-01

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · ERG-MESH-HB-RED-01打开导出工具

页面快速操作

发布采购询价

产品描述

This high-back ergonomic office chair combines a structured work-seating profile with a distinctive two-tone appearance. The tall back uses a light gray molded polypropylene outer frame and flexible light-gray mesh suspension, supporting the user while retaining a clean, open visual. A dark gray padded headrest sits above the back, while fixed gray polypropylene T-arms provide padded arm support. The red woven fabric seat creates a strong contrast with the gray frame and headrest. Its five-star aluminum-alloy base, twin-wheel polyurethane casters, chrome-plated steel gas lift, and black plastic shroud complete the mobile swivel-chair form. The overall layout is intended for users seeking head, lumbar, back, and arm support in a single task chair. Construction follows a conventional commercial office-chair arrangement, with a molded foam seat, mesh back, rigid polypropylene structure, steel tilt mechanism, steel gas lift, aluminum-alloy base, and polyurethane casters. The seat cushion uses red woven textile over high-resilience molded foam, with a finished cushion thickness of 90 mm and molded seat foam density of 45 kg/m3. Backrest padding is 70 mm thick, and the lumbar support zone is 240 mm high. The clear width between armrests is 540 mm, while the chair measures 670 x 680 x 1290 mm overall. A visible lever and tension knob beneath the seat provide accessible control. Functional features include pneumatic seat-height adjustment with an 80 mm stroke operated by the right-side lever. The synchro-tilt mechanism coordinates seat and back movement to a 115-degree recline and offers lockable upright and reclined positions. A rotary tension knob adjusts backward resistance to suit the user. The seat swivels 360 degrees and moves on five twin-wheel casters intended for hard floors and carpet. The recommended user weight is 135 kg. Product verification targets include a 102 kg seat static load, 68 kg force back-rest static load, 100000 caster rolling cycles, 200000 gas-lift height-adjustment cycles, and 50000 Martindale fabric abrasion acceptance. The chair is suited to executive workstations, open-plan offices, and home offices. It is recommended with desks 760 mm high and works on hard floors or low-pile carpet. Procurement teams should plan for one set supplied in two cartons, 23 kg packaged gross weight, 0.26 m3 carton volume, and 40 minutes assembly per set. A 20GP container can accommodate 135 sets at 85 percent space utilization. Buyers should also note the unbranded presentation, fixed armrests, bold red seat, and mesh-back aesthetic when coordinating with interior standards or workstation programs.

High-Back Mesh Ergonomic Office Chair with Headrest Specifications
