PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

数据来源：工厂资料结构化字段，最终以实测值为准

产品外部尺寸（宽 × 深 × 高）	620 × 620 × 1010 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

数据来源：产品性能数据，采购前请核对具体测试口径

Recommended user weight capacity	120 kg
Net weight	12.5 kg
Static seat-load verification target	660 kg
Caster rolling durability target	100,000 cycles
Gas-lift cycle target	100,000 height-adjustment cycles
Backrest cyclic load target	120,000 cycles
Fabric abrasion acceptance target	50,000 Martindale cycles
Seat foam density	45 kg/m3
Seat foam rebound	40%
Recommended users per day	1

PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

数据来源：以工厂材质清单与验货报告为准

Backrest support	Black flexible mesh panel in a black molded polymer frame
Seat upholstery	Green woven fabric over molded foam cushion
Seat cushion	70 mm molded polyurethane foam, 45 kg/m3 procurement density
Armrests	Black fixed loop arms with polymer contact pads and angled supports
Internal seat shell	12 mm molded plywood or polypropylene seat carrier
Gas lift	50 mm chrome-plated steel class-3 gas lift with black plastic sleeve

PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

数据来源：功能配置参数，以供应商正式规格为准

Seat height adjustment	Pneumatic lever raises and lowers the seat through a 100 mm stroke, with 440 mm selected as the lower procurement value
Back tilt	Weight-activated synchro tilt with 12-degree recline and upright lock position
Tilt tension	Rear rotary knob adjusts backward resistance for users up to 120 kg
Mobility	Five 50 mm twin-wheel casters enable rolling on carpet or hard floors

PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

数据来源：外贸报价与装柜测算参考

Carton dimensions	680 x 620 x 320 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

数据来源：依据产品结构与品类整理的推荐应用场景

Primary workplace	Individual workstations, open-plan offices and home offices where a compact mesh task chair is needed for 6-hour daily seating
Procurement configuration	Suitable for bulk staff seating with green seat accents and black neutral frames; pair with 720 to 760 mm high standard desks

STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

该市场暂无标准数据。

STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

该市场暂无标准数据。

招标文件标准化描述文本

本产品须满足以下技术参数要求：
1. 技术标准与检测报告由供应商在投标或采购确认阶段提供；
最终交付参数、检测报告和验收标准以双方采购合同为准。

GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告，可选择公制或英制单位。

PDF · OC-MESH-MB-50-GN

完整参数 Excel

导出全部商品信息与参数模块，文件内容统一使用英文。

XLSX · OC-MESH-MB-50-GN

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段，可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · OC-MESH-MB-50-GN打开导出工具

页面快速操作

发布采购询价

产品描述

The Mid-Back Mesh Swivel Task Chair with Green Seat is an unbranded office chair designed for practical daily use in individual workstations, open-plan offices, and home offices. Its balanced appearance combines a black flexible mesh back, black molded polymer frame, fixed loop arms, and five-star base with a green woven fabric seat, giving the chair a neutral commercial look with a distinct color accent. The mid-height back and compact 620 by 620 by 1010 mm footprint support an orderly layout in task-focused environments, while the 540 mm clear width between armrests leaves accessible room at the seat. Construction centers on a black mesh panel set in a molded polymer back frame. The seat uses green woven fabric over molded foam, with a 90 mm finished cushion and a 70 mm molded polyurethane cushion specified at 45 kg/m3 procurement density. A 12 mm molded plywood or polypropylene carrier supports the seat internally. Black fixed loop arms include polymer contact pads and angled supports, while the chair rests on a nylon five-star base with five 50 mm twin-wheel casters. Height movement is provided by a 50 mm chrome-plated steel class-3 gas lift with a black plastic sleeve. Functional features suit general desk work. A pneumatic lever controls seat height through a 100 mm stroke, using 440 mm as the lower procurement value. The weight-activated synchro tilt allows a 12-degree recline and includes an upright lock position, while a rear rotary knob adjusts backward resistance for users up to 120 kg. Swivel movement and twin-wheel casters support mobility across carpet or hard floors. The chair is suited to bulk staff seating where green seat accents can complement black frames and broader office furniture schemes. It is intended for six hours of daily seating and pairs with standard desks 720 to 760 mm high. Procurement teams should note the chair ships as one set across two cartons, with reference packaged gross weight of 23 kg per set, reference assembly time of 40 minutes per set, and reference carton volume of 0.26 m3 per set. Design validation targets include a 660 kg static seat-load verification target, 100,000 caster rolling cycles, 100,000 gas-lift height-adjustment cycles, 120,000 backrest cyclic loads, and 50,000 Martindale fabric abrasion cycles, making these useful criteria when comparing supplier samples and inspection expectations.

Mid-Back Mesh Swivel Task Chair with Green Seat Specifications
