Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1870 x 2170 x 1100 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Sleeping platform height from floor | 400 mm | |
| Under-bed floor clearance | 155 mm | |
| Headboard shelf depth | 200 mm | |
| Headboard side cubby internal dimensions | 250 x 250 x 180 mm | |
| Footboard height from sleeping platform | 250 mm | |
| Upholstered headboard panel thickness | 30 mm | |
| Support slat thickness | 25 mm | |
| Support slat spacing | 70 mm | |
| Angled support leg cross-section | 60 x 60 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 454 kg | |
|---|---|---|
| Recommended mattress thickness | 356 mm | |
| Number of supported sleepers | 2 | |
| Headboard shelf static load per shelf | 15 kg | |
| Slat system center support count | 3 | |
| Product net weight | 78 kg | |
| Upholstery abrasion resistance | 30000 cycles | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Bed frame main structure | Solid beech wood with light natural matte oil finish | |
|---|---|---|
| Headboard side shelf panels | Solid rubberwood with matching light oak finish | |
| Support slat system | Solid plywood slats with velcro fixing to side rails | |
| Center headboard panels | MDF core with linen upholstery and 25mm high-density foam padding | |
| Integrated lighting | Low-voltage 3000K warm white LED strip under top headboard shelf | |
| Support legs | Solid angled beech wood with rounded edge treatment | |
| Footboard panel | Solid beech wood with rounded top edge matching headboard styling | |
| Hardware connectors | Zinc-plated steel barrel bolts and dowel joinery | |
| Surface finish | E0-grade water-based matte wood finish | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Headboard storage layout | One full-width top ledge plus four symmetric open side cubbies (two per side) | |
|---|---|---|
| Integrated LED lighting | Warm white ambient strip light recessed under top headboard shelf | |
| Mattress support system | Slatted platform base eliminates need for separate box spring | |
| Padded headboard support | Two split upholstered panels provide upright back support for sitting in bed | |
| Rounded edge safety design | All exposed frame corners and edges feature radius rounding to reduce impact injury | |
| Matching nightstand compatibility | Designed to pair with matching two-drawer solid wood nightstands on either side | |
| KD assembly design | Flat-pack knock-down assembly with pre-drilled alignment holes | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Master bedrooms in modern Scandinavian-style residential apartments | |
|---|---|---|
| Target user group | Adult couples seeking combined sleeping surface and bedside open storage | |
| Recommended pairing | Match with two coordinating two-drawer light oak nightstands as shown in display | |
| Suitable mattress type | All standard memory foam, latex or innerspring mattresses up to 356mm thick | |
| Small space suitability | Ideal for compact bedrooms where separate bedside shelves are not feasible | |
| Ambient use case | Integrated LED provides soft low-level light for nighttime use without overhead lighting |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic seating and sleeping furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame strength and finish quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing | |
| GB/T 26706-2011 | General technical requirements for upholstered furniture beds, applicable for padding and structure safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame strength and finish quality; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission testing; 3. GB/T 26706-2011: General technical requirements for upholstered furniture beds, applicable for padding and structure safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
