Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 2150 x 950 mm | |
|---|---|---|
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 500 kg | |
|---|---|---|
| Product net weight | 75 kg | |
| Recommended user count | 2 | |
| Slat static load rating | 150 kg per slat | |
| Foam indentation load deflection | 35 kg | |
| Expected structural service life | 10 years | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Bed frame and legs | Solid rubberwood with natural clear matte finish | |
|---|---|---|
| Headboard outer cover | 280gsm linen-look polyester fabric | |
| Headboard padding | 35kg/m³ high-density polyurethane foam | |
| Mattress support slats | 12mm thick poplar plywood | |
| Upholstery attachment hardware | Zinc-plated steel staples and screw fasteners | |
| Headboard inner frame | 20mm thick oriented strand board | |
| Side rail joinery | Mortise and tenon with metal dowel reinforcement | |
| Decorative throw pillows | 220gsm polyester cover with 25kg/m³ polyfiber fill | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Integrated headboard support | Padded two-section upholstered backrest provides upright back support for seated reading | |
|---|---|---|
| Mattress support system | Fixed plywood slat base eliminates requirement for separate box spring | |
| Underbed clearance access | 200mm open floor gap allows robotic vacuum cleaning and low-profile storage | |
| Assembly mechanism | Knock-down construction with cam lock and bolt hardware for home assembly | |
| Headboard attachment | Bolts directly to side rail brackets with no separate wall mounting required | |
| Surface compatibility | Solid wood side rails retain mattresses to prevent lateral sliding | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Total shipping carton dimensions | 2080 x 650 x 220 mm (main frame); 1850 x 600 x 180 mm (headboard); 350 x 200 x 120 mm (hardware) | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential master bedroom application | Suits 18sqm master bedrooms as primary sleeping furniture for adult couples | |
|---|---|---|
| Small apartment guest room application | Low-profile frame and open underbed space maximizes usable floor area in compact rooms | |
| Matching furniture configuration | Pairs with 400mm wide two-drawer solid wood nightstands on both sides | |
| Daily use scenario | Supports both sleeping and upright seated use with padded headboard, suitable for reading or device use in bed |
EU Market Access Requirements* EN Standards
| Applicable domestic bed safety standard | EN 1725:2010 | |
|---|---|---|
| Applicable furniture emission standard | EN 16516:2017 |
Standards applicable to China-market projects
| Applicable furniture safety standard | GB/T 3324 | |
|---|---|---|
| Applicable upholstered furniture standard | GB/T 3327 | |
| Applicable textile formaldehyde limit | GB 18401Category B |
This product must meet the following technical requirements: 1. Applicable furniture safety standard: GB/T 3324; 2. Applicable upholstered furniture standard: GB/T 3327; 3. Applicable textile formaldehyde limit: GB 18401Category B; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
