Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2030 x 2210 x 1100 mm | |
|---|---|---|
| Headboard storage shelf internal height | 200 mm | |
| Sleeping platform height from floor | 250 mm | |
| Footboard height from floor | 380 mm | |
| Under-bed frame clearance | 155 mm | |
| Footboard book slot width per compartment | 320 mm | |
| Side rail panel thickness | 25 mm | |
| Support slat width | 63 mm | |
| Support slat spacing | 76 mm | |
| Center support rail count | 2 | |
| Headboard depth (shelf projection) | 150 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static weight capacity | 454 kg | |
|---|---|---|
| Recommended mattress thickness | 356 mm | |
| Headboard shelf weight capacity | 15 kg | |
| Footboard slot weight capacity per compartment | 5 kg | |
| Net bed frame weight without mattress | 70 kg | |
| Recommended user weight per side | 136 kg | |
| Surface abrasion resistance | 1000 cycles | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer frame panels | Engineered wood substrate with 0.6mm light oak veneer, matte UV finish | |
|---|---|---|
| Support slats | Solid poplar hardwood, sanded smooth unfinished | |
| Internal support frame | 25mm thick plywood with metal bracket reinforcements | |
| Assembly hardware | Zinc-plated steel bolts, cam locks, and corner brackets | |
| Headboard shelf backing | 3mm thick MDF with matching oak veneer finish | |
| Footboard slot dividers | 18mm thick engineered wood with matching edge banding | |
| Floor contact pads | 10mm thick non-slip polyethylene pads | |
| Side panel edges | Rounded 5mm radius edge banding matching frame finish | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Headboard open storage shelf | Fixed continuous top shelf for decor, books, and small bedside items, no moving parts | |
|---|---|---|
| Footboard vertical book slots | Two open fixed compartments for upright storage of books and magazines | |
| Slat support system | Fixed hardwood slat platform eliminates need for box spring, secured to rails with screws | |
| Center support structure | Two longitudinal support rails with center support legs for even weight distribution | |
| Assembly required | Cam-lock bolt assembly with included hex key, no special tools needed for home assembly | |
| Mattress anti-slip design | Slat surface with textured finish to prevent horizontal mattress shifting during use | |
| Floor protection | Integrated non-slip pads under frame rails and support legs to prevent floor scuffing | |
| Nightstand compatibility | Matching 2-drawer nightstands sized proportionally for placement on both sides | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential master bedroom | Suitable for wall placement against accent walls, provides bedside storage without separate shelves | |
|---|---|---|
| Small apartment bedrooms | Integrated storage eliminates need for separate bedside bookcases, saves floor space | |
| Nordic/Japanese style interiors | Light oak natural finish matches minimalist, natural-toned bedroom decor schemes | |
| Teen/guest bedrooms | Open book slots provide accessible storage for reading materials and personal items | |
| Pairing with low-profile mattresses | Designed to work with 350 mm thick mattresses for a low, modern bed silhouette | |
| Hardwood and carpeted floors | Non-slip floor pads work on both hard surface and soft carpeted flooring without scuffing |
EU Market Access Requirements* EN Standards
| EN 747-1:2012+A1:2015 | Furniture - bunk beds and domestic beds - safety requirements, applicable for edge and structural safety | |
|---|---|---|
| EN 12521:2015 | Furniture - strength, durability and safety for domestic seating, referenced for wood joint performance | |
| EN 13986:2004+A1:2015 | Wood-based panels for construction, performance specification for substrate materials |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for frame structural integrity | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor use safety | |
| GB/T 3327-2017 | Performance test methods for beds, applicable for static load and durability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for frame structural integrity; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor use safety; 3. GB/T 3327-2017: Performance test methods for beds, applicable for static load and durability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
