Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 2090 x 1120 mm | |
|---|---|---|
| Headboard height | 1120 mm | |
| Footboard rail height | 420 mm | |
| Under-bed ground clearance | 260 mm | |
| Side rail thickness | 63 mm | |
| Headboard panel thickness | 50 mm | |
| Recommended mattress thickness | 220 mm | |
| Slat spacing | 75 mm | |
| Leg cross-section dimension | 70 x 70 mm | |
| Mattress support platform height | 320 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 363 kg | |
|---|---|---|
| Product net weight | 55 kg | |
| Slat static load per unit | 110 kg | |
| Recommended maximum user weight | 136 kg | |
| Recommended mattress weight | 45 kg | |
| Finish abrasion resistance | 4000 cycles | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard panel | Solid natural oak with matte clear lacquer finish | |
|---|---|---|
| Side rails and foot rail | Solid natural oak with smooth sanded edges | |
| Support legs | Solid oak square block legs, fixed screwed installation | |
| Support slats | Solid pine horizontal slats, fixed to frame cross members | |
| Center support beam | Galvanized steel rectangular center beam with middle support leg | |
| Hardware connectors | Zinc-plated steel screws, wood dowels, glue joints | |
| Surface finish | Matte clear nitrocellulose lacquer, low VOC emission level | |
| Edge treatment | Rounded 2mm radius sanded edges on all exposed wood surfaces | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support | Fixed slatted platform design, no box spring required for standard mattress use | |
|---|---|---|
| Assembly method | Knock-down screwed and doweled assembly, two-person installation required | |
| Under-bed access | Open unobstructed under-bed space for robot vacuum cleaning access | |
| Mattress retention | Raised side rail lips to prevent mattress lateral sliding during use | |
| Headboard backing | Solid panel headboard with wall clearance gap for standard pillow placement | |
| Center support | Continuous center beam with one middle support leg to eliminate slat sag | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application | Residential master or guest bedroom use for adult sleeping accommodation | |
|---|---|---|
| Style matching | Suitable for Scandinavian, Japandi, modern minimalist bedroom interior design schemes | |
| Supporting furniture pairing | Pairs with matching light oak 2-drawer nightstands and low dresser for coordinated bedroom set | |
| Floor compatibility | Suitable for wood flooring, tile or low-pile area rug placement, no floor damage risk with included felt pads | |
| User group | Designed for adult couples or single adult users in residential household settings | |
| Space requirement | Minimum bedroom width of 2700mm to allow bedside access and nightstand placement |
EU Market Access Requirements* EN Standards
| EN 1725:2012 | Domestic furniture beds and mattresses safety requirements, applicable for stability and durability testing | |
|---|---|---|
| EN 71-3:2019 | Toy safety migration of elements, applicable for edge and surface safety for household use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde testing | |
| GB/T 10357.6-2013 | Furniture mechanical performance test for beds, applicable for strength and stability verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde testing; 3. GB/T 10357.6-2013: Furniture mechanical performance test for beds, applicable for strength and stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
