Automatic mm / inch conversion · Core engineering specifications
| Overall bed footprint (mattress support area included) | 1600 x 2200 x 980 mm | |
|---|---|---|
| Fits standard mattress dimensions | 1520 x 2030 mm | |
| Headboard height from floor | 980 mm | |
| Footboard height from floor | 420 mm | |
| Platform slat surface height from floor | 355 mm | |
| Under-bed clearance between floor and rail | 203 mm | |
| Individual matching nightstand footprint | 500 x 400 x 500 mm | |
| Bed leg cross-section dimension | 60 x 60 mm | |
| Headboard panel thickness | 25 mm | |
| Footboard panel thickness | 20 mm | |
| Wooden slat width | 70 mm | |
| Slat spacing between adjacent slats | 89 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity (bed frame) | 340 kg | |
|---|---|---|
| Recommended mattress thickness | 203 mm | |
| Total set net weight (bed + 2 nightstands) | 113 kg | |
| Recommended number of users | 2 | |
| Finish abrasion resistance rating | 2000 cycles | |
| Wood slat static load per slat | 30 kg | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Bed frame structural components | Solid pine wood with matte natural clear finish | |
|---|---|---|
| Support slat system | Solid pine wood slats with steel center support beam | |
| Headboard panel | Solid edge-glued pine wood panel with rounded top edges | |
| Footboard panel | Solid pine wood panel with mitered corner joinery | |
| Bed legs | Solid turned pine wood tapered legs with floor protection pads | |
| Nightstand drawer fronts and carcass | Solid pine wood with matching natural wood finish | |
| Drawer slides (nightstands) | Cold-rolled steel side-mount 3-extension slides | |
| Hardware fasteners | Zinc-plated steel bolts, barrel nuts and wood screws | |
| Finish coating | Low-VOC water-based clear wood sealant | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Support system configuration | Wooden slat platform eliminates need for separate box spring | |
|---|---|---|
| Center support structure | 3 additional center support legs distribute weight to prevent slat sag | |
| Nightstand storage configuration | 2 full-width soft-close drawers per nightstand for bedside storage | |
| Under-bed access | Open under-bed clearance allows for flat storage bins or cleaning access | |
| Assembly requirement | Knock-down flat pack assembly with included hardware and instructions | |
| Mattress retention design | Recessed side and end rails prevent mattress sliding during use | |
| Nightstand configuration | 2 freestanding matching nightstands positioned on either side of bed | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms or guest bedrooms with Scandinavian or minimalist interior design | |
|---|---|---|
| Target user group | Adult users seeking durable, chemical-free solid wood bedroom furniture without box spring requirements | |
| Recommended configuration pairing | Pair with 250 mm thick memory foam, latex or spring mattress for optimal sleep comfort | |
| Layout recommendation | Position with nightstands flanking headboard, leave 600mm minimum clearance on both sides for easy access | |
| Style compatibility | Coordinates with light wood, neutral gray, white and natural textile bedroom decor palettes | |
| Use case suitability | Suitable for daily long-term domestic use, including rental properties and small apartment bedrooms |
EU Market Access Requirements* EN Standards
| EN 1725:1998 Domestic furniture - Beds and mattresses - Safety requirements and test methods | Applicable for structural safety, edge and stability performance testing | |
|---|---|---|
| EN 12521:2015 Furniture - Strength, durability and safety - Requirements for domestic tables | Applicable for matching nightstand structural strength verification |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for wooden furniture | Applicable for wooden frame strength, dimensional stability and finish quality inspection | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for formaldehyde and VOC emission limit verification for indoor bedroom use |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for wooden furniture: Applicable for wooden frame strength, dimensional stability and finish quality inspection; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for formaldehyde and VOC emission limit verification for indoor bedroom use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
