Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1717 x 2197 x 1107 mm | |
|---|---|---|
| Inner mattress fit area | 1524 x 2032 mm | |
| Headboard dimensions | 1651 x 65 x 1000 mm | |
| Sleeping surface height from floor | 340 mm | |
| Underbed clearance | 267 mm | |
| Side rail thickness | 30 mm | |
| Headboard padding thickness | 65 mm | |
| Leg height | 267 mm | |
| Foot end rail height | 250 mm | |
| Slat width | 70 mm | |
| Slat spacing gap | 76 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Static total load capacity | 363 kg | |
|---|---|---|
| Recommended mattress thickness | 305 mm | |
| Slat support count | 13 | |
| Center support leg count | 4 | |
| Net product weight | 47 kg | |
| Fabric upholstery abrasion resistance | 30000 double rubs | |
| Foam padding density | 32 kg/m³ | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Bed frame and legs | Solid rubberwood with light oak matte finish | |
|---|---|---|
| Internal support structure | LVL engineered wood slats and cross beams | |
| Headboard upholstery | 100% polyester linen-look off-white fabric | |
| Headboard padding | High-resilience polyurethane foam | |
| Hardware connectors | Zinc-plated steel bolts and barrel nuts | |
| Frame surface finish | Low-VOC water-based clear lacquer | |
| Tufting fasteners | Matching fabric-covered buttons | |
| Center support brackets | 1.5mm thick powder-coated steel | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support system | Wood slat platform eliminates requirement for box spring | |
|---|---|---|
| Underbed storage access | Open 267mm clearance for under-bed storage bins and footwear | |
| Headboard installation | Bolt-on attachment to side rails with pre-drilled mounting holes | |
| Assembly requirement | Knock-down assembly with included hex key and hardware | |
| Mattress retention | Recessed side rail lip prevents mattress sliding off platform | |
| Noise reduction design | Felt pads between slats and frame eliminate squeaking during use | |
| Headboard tufted design | Grid-pattern button tufting creates segmented padded panels | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 2240 x 460 x 180 mm (largest carton) | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential master bedroom | Suitable for queen size bedrooms with Scandinavian or mid-century modern decor | |
|---|---|---|
| Small urban apartment | Low-profile design creates visual openness without occupying excessive vertical space | |
| Guest bedroom furnishing | Neutral off-white and light oak finish matches varied guest room color schemes | |
| Studio apartment flexible layout | Open underbed storage maximizes usable floor space in compact units | |
| Pairing recommendation | Matches light wood two-drawer nightstands for coordinated bedroom set | |
| User suitability | Ideal for adult users preferring firm mattress support without box spring |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 1022:2005 | Domestic furniture - Seating - Determination of stability, applicable to edge load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structural stability | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture | |
| GB/T 1952.2-2011 | General technical requirements for upholstered furniture, applicable to upholstered headboard |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structural stability; 2. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances for wooden furniture; 3. GB/T 1952.2-2011: General technical requirements for upholstered furniture, applicable to upholstered headboard; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
