Automatic mm / inch conversion · Core engineering specifications
| Overall external dimensions | 1890 x 2180 x 1130 mm | |
|---|---|---|
| Compatible mattress size | 1800 x 2000 mm | |
| Headboard height from floor | 1130 mm | |
| Footboard height from floor | 420 mm | |
| Mattress support surface height from floor | 330 mm | |
| Underbed clearance height | 200 mm | |
| Headboard panel thickness | 45 mm | |
| Side rail thickness | 35 mm | |
| Square support leg cross-section | 60 x 60 mm | |
| Horizontal slot opening height on headboard/footboard | 80 mm | |
| Slat support thickness | 20 mm | |
| Slat spacing between supports | 80 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Total static load capacity | 320 kg | |
|---|---|---|
| Number of support slats | 14 | |
| Number of center support beams | 2 | |
| Recommended maximum mattress thickness | 250 mm | |
| Net frame weight (without mattress) | 46 kg | |
| Finish abrasion resistance | 1000 cycles | |
| Connector static shear strength | 800 kg | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard/footboard/side rails | Solid natural hardwood with clear matte wood wax oil finish | |
|---|---|---|
| Mattress support slats | Solid pine wood, sanded smooth, no sharp edges | |
| Center support beams | Solid hardwood, 70mm width, connected to side rails with metal brackets | |
| Support legs | Solid square hardwood legs, with non-slip floor glides | |
| Connection hardware | Zinc-plated steel bolts, barrel nuts, and corner brackets | |
| Surface finish | Low-VOC clear wood wax oil, no added formaldehyde | |
| Floor glides | High-density polyethylene non-scratch glides on each leg base | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
Adjustment / rotation / tilt / mobility / storage features
| Mattress support | Solid wood slat platform, no box spring required for use | |
|---|---|---|
| Assembly | Knock-down assembly with included hex key and hardware, no special tools needed | |
| Floor leveling | Fixed non-adjustable glides on each leg, suitable for flat hard floors | |
| Storage access | Open underbed space for low-profile storage bins, no built-in drawers | |
| Headboard function | Horizontal open slot design for air circulation, no upholstered padding | |
| Structural connection | Reinforced corner brackets to reduce frame wobble during use | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Residential master bedroom | Suitable for 1800mm queen size mattress, two-adult daily sleeping use | |
|---|---|---|
| Small apartment bedroom | Low-profile design without built-in storage, light color expands visual space | |
| Nordic/Japanese style interiors | Light natural wood finish, clean lines, no excessive decoration | |
| Guest bedroom | Durable solid wood construction for frequent guest use, easy maintenance | |
| Hard surface flooring | Non-scratch floor glides prevent damage to wood, tile, or laminate floors |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic furniture - Beds and mattresses - Safety requirements and test methods | |
|---|---|---|
| EN 747-1:2012 | Furniture - Bunk beds and high beds for domestic use - Safety requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to dimensional and structuralAcceptance | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applies to formaldehyde and heavy metal limits |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to dimensional and structuralAcceptance; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applies to formaldehyde and heavy metal limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
