Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 640 x 2200 mm | |
|---|---|---|
| Leg height | 120 mm | |
| Integrated drawer front height | 180 mm | |
| Door panel infill count | 4 per door | |
| Internal hanging compartment height | 1100 mm | |
| Internal shelf depth | 580 mm | |
| Drawer internal width per door | 820 mm | |
| Drawer internal depth | 550 mm | |
| Top panel thickness | 25 mm | |
| Side panel thickness | 18 mm | |
| Base clearance under unit | 100 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total unit gross weight | 140 kg | |
|---|---|---|
| Clothes rail static load capacity | 25 kg | |
| Sliding door cycle durability | 50000 open/close cycles | |
| Drawer slide cycle durability | 30000 open/close cycles | |
| Recommended maximum user load per hanging section | 40 standard shirts | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer frame and legs | Solid light oak with clear matte lacquer finish | |
|---|---|---|
| Door infill panels | 18mm thick E1 grade particleboard with matte off-white laminate | |
| Carcass core (sides, top, base) | 18mm thick E0 grade engineered wood with oak veneer matching frame | |
| Back panel | 9mm thick hardboard with oak grain overlay | |
| Drawer boxes | 12mm thick plywood with smooth matte interior finish | |
| Edge banding | 1mm thick PVC edge band matching frame color on all cut panels | |
| Sliding door tracks and rollers | Anodized aluminum top/bottom tracks with nylon roller wheels | |
| Drawer slides | Side-mounted 3-section cold-rolled steel ball-bearing slides | |
| Anti-tip hardware | 2 zinc-plated steel wall anchor brackets with mounting screws | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Door operation | 2-panel bypass sliding system with full horizontal travel to access either side compartment | |
|---|---|---|
| Integrated drawer access | 1 recessed pull drawer per sliding door positioned at mid-door height, accessible without moving doors | |
| Internal storage layout | Full-height hanging rail on one side, 4 adjustable shelves and 2 door-integrated drawers on the opposite side | |
| Shelf adjustability | 5 position shelf pins at 32mm spacing for custom shelf height configuration | |
| Leveling function | 4 adjustable feet at leg bases to compensate for uneven wood flooring | |
| Sliding door lock | Optional central door lock to secure both sliding panels when fully closed | |
| Door damping | Soft-close buffer mechanism on track ends to prevent slamming during operation | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary use space | Residential master or guest bedroom, placed against flat wall near ceiling height | |
|---|---|---|
| Target user | Households requiring mixed hanging and folded clothing storage in Nordic-style interiors | |
| Placement requirement | Minimum 2230 mm ceiling height, 50 mm rear clearance from wall for sliding track operation | |
| Recommended matching furniture | Light oak bed frame, white nightstands, light wood flooring to coordinate with finish palette | |
| Storage suitability | Holds up to 60 hanging garments plus 25 folded items in drawers and shelves | |
| Assembly recommendation | Two-person assembly required to safely handle tall heavy panels and attach anti-tip hardware |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety requirements for domestic storage furniture, including anti-tip stability requirements | |
|---|---|---|
| EN 312:2010 | Performance requirements for particleboard used in furniture structural components | |
| EN 12521:2015 | Durability requirements for furniture hardware including slides and hinges |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to carcass dimensional tolerances and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, minimum E1 grade required for indoor use | |
| GB/T 4893.8-2013 | Surface abrasion resistance test method for furniture coatings, minimum 2000 wear cycles required |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to carcass dimensional tolerances and finish quality; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, minimum E1 grade required for indoor use; 3. GB/T 4893.8-2013: Surface abrasion resistance test method for furniture coatings, minimum 2000 wear cycles required; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
