Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 600 x 2000 mm | |
|---|---|---|
| Floor clearance under cabinet | 150 mm | |
| Single door panel width | 440 mm | |
| Single door panel height | 1820 mm | |
| Internal hanging compartment height | 1200 mm | |
| Upper shelf depth | 560 mm | |
| Handle length | 150 mm | |
| Leg splay angle from vertical | 12 degrees | |
| Internal width between side panels | 860 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight | 50 kg | |
|---|---|---|
| Maximum static load per adjustable shelf | 20 kg | |
| Maximum static load for hanging rod | 30 kg | |
| Recommended maximum user load for full cabinet | 120 kg | |
| Hinge cycle durability | 80000 open/close cycles | |
| Product warranty period | 3 years | |
| Available color finish count | 2 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Support legs | Solid ash wood tapered splayed legs, clear matte lacquer finish | |
|---|---|---|
| Outer cabinet frame | Solid ash wood edge frame, 20mm thick, matte natural finish | |
| Door panels | 15mm thick medium-density fiberboard, matte white PU paint finish | |
| Carcass internal panels | 15mm thick particleboard, white melamine internal finish | |
| Back panel | 3.5mm thick hardboard, white finish | |
| Door pulls | Brushed light gold zinc alloy vertical handles | |
| Hinges | Cold-rolled steel concealed adjustable hinges, nickel plated | |
| Internal hanging rod | 25mm diameter chrome-plated steel tube | |
| Edge banding | 1mm thick PVC edge banding on all engineered wood cut edges | |
| Internal shelves | 15mm thick melamine-faced particleboard, adjustable on metal pins | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Door operation | Dual opposing hinged doors, 110-degree opening angle, adjustable hinge alignment | |
|---|---|---|
| Anti-tip safety | 2 steel wall anchor straps included, secured to wall studs for tip-over prevention | |
| Internal configuration | One full-width steel hanging rod below two adjustable upper storage shelves | |
| Shelf adjustability | 5 vertical shelf pin positions, 32mm spacing, to reposition upper shelves | |
| Assembly structure | Knock-down flat-pack assembly, cam-lock and dowel joinery | |
| Leg level adjustment | Fixed solid wood legs without adjustable floor glides | |
| Door alignment | Hinges support 3-way adjustment for door gap and flush alignment | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Small residential bedroom | Fits 900mm width floor footprints for compact apartment or rental room use | |
|---|---|---|
| Entryway/mudroom | Provides enclosed outerwear storage for entry spaces next to coat racks | |
| Small studio apartment | Functions as dual clothing and linen storage without occupying excess floor area | |
| Rental property furnishing | Durable two-tone design matches Nordic decor schemes for furnished rentals | |
| Youth bedroom | Compact height fits teen rooms for hanging school uniforms and casual clothing |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage furniture safety requirements, applicable for tip-over and structural safety | |
|---|---|---|
| EN 312:2010 | Particleboard specifications, applicable for quality verification of engineered wood panels |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and dimensional acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wood furniture, mandatory for formaldehyde testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and dimensional acceptance; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wood furniture, mandatory for formaldehyde testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
