Automatic mm / inch conversion · Core engineering specifications
| Carcass Panel Thickness | 25 mm | |
|---|---|---|
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Static load per hanging rod | 30 kg | |
|---|---|---|
| Static load per open shelf | 15 kg | |
| Central drawer static load | 10 kg | |
| Total unit static load capacity | 165 kg | |
| Unit net weight | 52 kg | |
| Hanging space garment capacity (upper zone) | 15 pieces | |
| Hanging space garment capacity (lower zone) | 12 pairs | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet frame and panels | 18mm thick engineered wood with light natural oak veneer finish | |
|---|---|---|
| Upper hanging rod | 25mm diameter chrome-plated steel | |
| Lower hanging rod | 25mm diameter chrome-plated steel | |
| Drawer hardware | Recessed dark metal pull handle, side-mounted ball bearing slides | |
| Base support legs | 50mm tall solid wood legs matching cabinet finish | |
| Shelf surfaces | 18mm thick engineered wood with matching oak finish, smooth sealed edge | |
| Back panel | 5mm thick hardboard backing with light oak finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Dual-zone hanging storage | Upper rod holds short garments, lower rod holds long trousers, no obstructing doors for quick access | |
|---|---|---|
| Central pull-out drawer | Single full-extension drawer provides concealed storage for small clothing items and accessories | |
| Five-tier right open shelving | Five fixed open shelves hold stacked folded clothing, storage boxes and accessories for visible organization | |
| Elevated moisture-resistant base | Raised 100mm off the floor prevents panel damage from floor mopping or ground moisture | |
| Freestanding installation | No wall anchoring required for standard placement, integrated leg levelers compensate for uneven floors | |
| Tool-free shelf adjustability | Fixed shelf positions with pre-drilled holes allow shelf height repositioning for oversized items | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Bedroom main clothing storage | Suitable for 2person household bedroom open clothing storage, supports both hung and folded items | |
|---|---|---|
| Rental apartment furnished configuration | Light natural finish fits modern and Scandinavian interiors, easy to assemble and move between properties | |
| Small apartment entryway coat storage | Compact footprint works for entryway or dressing nook for outerwear, bags and daily accessories | |
| Studio apartment space-saving storage | Open design reduces visual bulk in small studio spaces, no need for dedicated closed closet room |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
