| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2030 x 660 x 2400 mm | |
|---|---|---|
| Top storage cabinet height | 400 mm | |
| Lower main wardrobe body height | 2000 mm | |
| Base leg height | 100 mm | |
| Floor clearance under cabinet | 80 mm | |
| Main sliding door panel height | 1900 mm | |
| Single upper hinged door width | 507 mm | |
| Interior hanging rail height | 1700 mm | |
| Interior shelf depth | 580 mm | |
| Main door track thickness | 12 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total unit net weight | 215 kg | |
|---|---|---|
| Hanging rail static load capacity | 60 kg | |
| Sliding door cycle rating | 10000 open/close cycles | |
| Upper cabinet door hinge load rating | 15 kg per door | |
| Recommended maximum user weight for top surface | 50 kg | |
| Structural warranty period | 1 year | |
| Available color options | 2 | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet frame and side panels | 18mm thick solid pine wood with clear water-based finish | |
|---|---|---|
| Sliding door panels | 15mm thick solid wood recessed shaker panels | |
| Upper hinged doors | 15mm thick solid wood recessed shaker panels | |
| Support legs | 40x40mm solid wood square legs | |
| Door hardware pulls | Dark brass finished metal vertical pulls | |
| Sliding door track system | Zinc-plated steel bypass sliding track | |
| Upper door hinges | Cold-rolled steel soft-close concealed hinges | |
| Interior hanging rail | 25mm diameter oval solid wood hanging rod | |
| Interior adjustable shelves | 18mm thick solid wood panels with metal shelf pins | |
| Surface finish | Matte clear water-based polyurethane coating | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Main door operation | Two bypass sliding doors run on top/bottom tracks for full access to either storage bay | |
|---|---|---|
| Interior storage configuration | Dual-zone layout with dedicated long-hanging section and stacked adjustable shelf section | |
| Door damping function | Soft-close mechanism on sliding tracks and upper hinges to prevent slamming | |
| Shelf adjustability | Shelves mount on twin rows of pin holes to support 50mm vertical height adjustments | |
| Floor clearance function | 80mm under-cabinet gap enables easy floor cleaning and robot vacuum access | |
| Wall anchoring provision | Pre-drilled anti-tip bracket points at rear top corners for secure wall attachment | |
| Assembly structure | Knock-down construction with cam lock and dowel connectors for on-site assembly | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Primary application space | Residential master bedrooms, positioned against wall corners for full clothing storage | |
|---|---|---|
| Secondary application space | Guest bedrooms or studio apartments requiring enclosed, space-saving clothing storage | |
| Target user group | Households preferring natural wood Scandinavian or shaker style interior design | |
| Complementary furniture pairing | Pairs with matching natural wood bed frames, nightstands and dressers for cohesive bedroom sets | |
| Storage suitability | Stores long garments, folded clothing, bedding and seasonal items across dual lower and upper zones | |
| Installation note | Requires 50mm clearance from adjacent walls for sliding door operation and wall anchor installation |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units safety requirements, applicable for structural stability verification | |
|---|---|---|
| EN 16122:2012 | Domestic furniture storage units test methods for strength and durability, applicable for load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structural acceptance | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission verification | |
| GB/T 4893.8-2013 | Furniture surface test for wear resistance, applicable for finish durability acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structural acceptance; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture, applicable for formaldehyde emission verification; 3. GB/T 4893.8-2013: Furniture surface test for wear resistance, applicable for finish durability acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
