Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 590 x 2000 mm | |
|---|---|---|
| Under-base clearance | 180 mm | |
| Internal storage width | 860 mm | |
| Internal storage depth | 550 mm | |
| Hanging zone height | 1200 mm | |
| Folded storage zone height | 620 mm | |
| Leg height | 180 mm | |
| Door panel thickness | 22 mm | |
| Carcass side panel thickness | 18 mm | |
| Back panel thickness | 9 mm | |
| Adjustable shelf thickness | 18 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Hanging rail static load capacity | 15 kg | |
|---|---|---|
| Product net weight | 72 kg | |
| Hinge open/close cycle rating | 80000 cycles | |
| Drawer slide load rating (if fitted) | 15 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Door frame | Solid hardwood with walnut wood grain finish, 22mm thick recessed panel construction | |
|---|---|---|
| Carcass panels | High-density engineered wood core with walnut veneer, 18mm thick | |
| Back panel | Engineered hardboard with matching wood finish, 9mm thick | |
| Support legs | Solid tapered hardwood, walnut finish, bolt-mounted to base frame | |
| Hanging rail | Chrome-plated solid steel, 25mm diameter, wall-mounted to side panels | |
| Door pull handle | Recessed dark-finish metal vertical pull, full-length recessed mounting | |
| Door hinges | Soft-close metal concealed hinges, 110-degree opening angle | |
| Surface finish | Natural wood wax oil coating, matte walnut tone, low VOC | |
| Edge banding | Solid wood edge lipping, 1.5mm thick, matched to door finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Door operation | Two hinged doors open to 110 degrees with soft-close damping to prevent slamming | |
|---|---|---|
| Interior layout | Upper full-width hanging rail for long garments, lower adjustable shelf for folded items | |
| Safety feature | Includes 2 wall-mounted anti-tip anchors to prevent forward tipping during use | |
| Shelf adjustability | 2 adjustable shelf positions with 32mm hole spacing to customize storage height | |
| Assembly requirement | Legs attach to pre-assembled carcass with included hardware, no specialist tools needed | |
| Door alignment | Concealed hinges include 3-way adjustment to align door gaps after installation | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 | |
|---|---|---|
| Shipping carton dimensions | 990 x 610 x 1750 mm | |
| Gross shipping weight | 79 kg | |
| Shipping volume per unit | 1.06 CBM | |
| On-site assembly time | 50 minutes | |
| 20ft container loading quantity | 26 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons |
Recommended spaces / users / usage modes
| Residential bedroom storage | Suitable for master or guest bedrooms to store hanging and folded clothing | |
|---|---|---|
| Studio apartment storage | Compact 900mm width fits small studio spaces without occupying excess floor area | |
| Mid-century modern interior schemes | Walnut finish and tapered leg design complements Scandinavian and mid-century room decor | |
| Freestanding placement | No built-in installation required, can be positioned against any flat interior wall | |
| Children's bedroom use | Wall anchor anti-tip feature reduces safety risk for high-traffic family spaces |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Domestic and kitchen storage units and worktops - Safety requirements, applicable to wardrobe stability and anti-tip performance | |
|---|---|---|
| EN 717-1:2004 | Wood-based panels - Determination of formaldehyde release, applicable to core panel emission limits |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wooden wardrobe structural safety and finish quality | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wooden wardrobe structural safety and finish quality; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to formaldehyde emission testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
