Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 550 x 780 mm | |
|---|---|---|
| Desktop thickness | 18 mm | |
| Per-seat desktop length | 600 mm | |
| Knee clearance height under desk | 750 mm | |
| Modesty panel height | 450 mm | |
| Floor mounting footplate size | 150 x 150 mm | |
| Steel leg tube wall thickness | 2 mm | |
| Wire basket depth under desk | 150 mm | |
| Edge trim radius | 5 mm | |
| Row spacing requirement for installation | 1200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 180 kg | |
|---|---|---|
| Unit net weight | 65 kg | |
| Formaldehyde emission limit for wood panels | 0.5 mg/L | |
| Surface abrasion resistance rating | 2000 cycles | |
| Minimum service life | 5 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core and finish | 18mm MDF core with wood-grain melamine laminate | |
|---|---|---|
| Desktop edge trim | 2mm light gray PVC edge banding with rounded corners | |
| Frame and leg assembly | Powder-coated dark green cold-rolled steel | |
| Floor footrest plates | Textured galvanized steel footplates with anti-slip ridges | |
| Front modesty panel | Wood-grain laminate panel secured in steel frame | |
| Under-desk storage basket | Black epoxy-coated steel wire mesh basket | |
| Frame surface treatment | Acid pickled, phosphated, electrostatic powder coated | |
| Anchor hardware | Galvanized steel expansion bolts for concrete floor mounting | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Mounting system | Permanent floor anchoring via 3 leg assemblies with bolted footplates | |
|---|---|---|
| Storage provision | Continuous front undermount wire basket for student books and supplies | |
| Privacy barrier | Full-height front modesty panel blocking leg visibility for seated users | |
| Ergonomic seating support | Curved cantilever legs providing unobstructed knee clearance for 3 users | |
| Surface utility | Slightly sloped melamine writing surface with stain and water resistance | |
| Foot support | Integrated ridged footrests at each leg base for seated student comfort | |
| Durability performance | Welded steel joints with no sharp edges, meeting school safety requirements | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| K-12 and university standard classrooms | Permanent row seating for lecture-based learning with integrated storage | |
|---|---|---|
| Training and examination halls | Fixed forward-facing seating for high-use formal assessment environments | |
| Multimedia teaching rooms | Sloped writing surface suitable for note-taking during projected presentations | |
| Vocational education facilities | Heavy-duty construction suitable for daily long-term student use | |
| Auditorium and lecture hall auxiliary seating | Fixed installation for tiered or flat-floor large-group learning spaces |
EU Market Access Requirements* EN Standards
| EN 1729-1:2015 | Applicable safety and strength requirements for educational furniture | |
|---|---|---|
| EN 1729-2:2012 | Applicable test methods for strength, durability and stability of school desks |
Standards applicable to China-market projects
| GB/T 3976-2014 | Applicable to sizing and functional dimensions for school desks and chairs | |
|---|---|---|
| GB 18580-2017 | Applicable formaldehyde emission limit for wood-based panel components | |
| GB/T 3324-2017 | Applicable general technical requirements for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3976-2014: Applicable to sizing and functional dimensions for school desks and chairs; 2. GB 18580-2017: Applicable formaldehyde emission limit for wood-based panel components; 3. GB/T 3324-2017: Applicable general technical requirements for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
