PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1240 × 790 × 1020 mm
Overall unit dimensions (2 ganged seats)	1240 x 790 x 1020 mm
Individual seat center width	620 mm
Seat height from floor to cushion top	450 mm
Armrest height from floor to arm cap	620 mm
Inner seat usable width between armrests	530 mm
Seat cushion depth (front to back)	500 mm
Backrest height from seat surface to top	570 mm
Round pedestal base diameter	380 mm
Armrest cap dimensions	422 x 80 x 29 mm
Perforated modesty panel dimensions per seat	450 x 600 x 15 mm
Backrest foam thickness	95 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Per-seat net weight (unassembled)	26 kg
Recommended static load per seat	160 kg
Seat mechanism spring return cycle rating	100000 cycles
Fabric abrasion resistance (Martindale)	50000 cycles
Foam density (seat cushion)	65 kg/m³
Foam density (backrest)	55 kg/m³
Seat tip-up soft-close damping time	3 seconds
Internal steel frame thickness	2.0 mm
Seat foam thickness (compressed loaded)	75 mm
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Seat and back upholstery	Blue wear-resistant woven public-seating fabric, anti-pilling, colorfast, breathable
Seat cushion padding	Cold-molded high-resilience PU foam, 65 kg/m³, 75mm thick
Backrest padding	Cold-molded high-resilience PU foam, 55 kg/m³, 95mm thick, contoured lumbar support
Armrest caps	Solid varnished hardwood with reddish-brown polished finish
Armrest support brackets	Matte black powder-coated die-cast aluminum/steel, integrated number plate mount
Front modesty panels	Reddish-brown perforated wood-composite panel, uniform acoustic ventilation holes
Internal support frame	2.0 mm cold-rolled steel, phosphated anti-rust treated, electrostatic powder coated
Pedestal bases	Black powder-coated perforated steel column + round steel floor flange, expansion bolt fixed
Side panels	3 mm density board upholstered with matching blue fabric
Seat return mechanism	Dual steel spring with silicone damping buffer, silent automatic tip-up
Seat/back inner support panels	10 mm thick high-density plywood, shaped for ergonomic contour
Surface stitching	Reinforced polyester thread, 8 mm seam pitch, horizontal channel stitching on back

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat tip-up operation	Automatic dual-spring damped return to vertical position when unoccupied, soft close to eliminate impact noise
Floor installation	Permanent fixed mount via hex expansion bolts through round base flanges, with plastic dust caps over fasteners
Ganged row alignment	Adjacent seats connected via shared armrest brackets for uniform row spacing and structural rigidity
Acoustic performance	Perforated front modesty panels diffuse reflected sound to reduce echo in large assembly halls
Mounting accessory compatibility	Armrest supports pre-configured for seat/row number plates, optional cup holders or writing tablets
Fire safety customization	Upholstery and foam available with B1 flame-retardant treatment for public assembly code compliance
Seat access clearance	Tip-up seat provides 300 mm minimum row passage clearance when folded upright
Back support ergonomics	Triple-curved contoured back with horizontal channel quilting supports lumbar, mid-back and shoulder regions
Finish customization	Wood panel finish, fabric color, and embroidery options available to match venue interior design
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Large auditorium and lecture hall	Permanent row installation for tiered or flat-floor venues, supports long-duration event seating for audiences
Conference center and government assembly hall	Formal wood-trim aesthetic matches official venue design, quiet tip-up mechanism minimizes meeting disruption
University and college lecture theater	Durable construction withstands daily high-frequency student use, ergonomic support improves long-class comfort
Cinema and performing arts theater	Perforated panels support venue acoustic design, tip-up seats improve passage clearance between rows
Church and multi-purpose public assembly space	Ganged configuration maintains orderly row alignment, customizable finishes match venue decorative schemes
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 12727:2016	Applies to ranked public seating; specifies strength, stability and durability test methods for fixed auditorium chairs
EN 1021-1:2014	Applies to upholstered furniture; specifies smouldering cigarette ignition resistance requirements for public venue seating
EN 1021-2:2014	Applies to upholstered furniture; specifies match flame ignition resistance requirements for public seating fabrics and foam

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB 20286-2006	Applies to public venue furniture; sets flame retardant performance requirements for upholstered seating components
GB/T 3324-2017	Applies to general wooden furniture; specifies finish adhesion, wear resistance and panel strength requirements for wood trim
GB/T 1952.1-2012	Applies to upholstered furniture; sets foam resilience, fabric durability and structural safety requirements for seating

Standardized tender description text

This product must meet the following technical requirements:
1. GB 20286-2006: Applies to public venue furniture; sets flame retardant performance requirements for upholstered seating components;
2. GB/T 3324-2017: Applies to general wooden furniture; specifies finish adhesion, wear resistance and panel strength requirements for wood trim;
3. GB/T 1952.1-2012: Applies to upholstered furniture; sets foam resilience, fabric durability and structural safety requirements for seating;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · AUD-2SEAT-BL-FAB-PED

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · AUD-2SEAT-BL-FAB-PED

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · AUD-2SEAT-BL-FAB-PEDOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This unbranded two-seat ganged auditorium chair, model AUD-2SEAT-BL-FAB-PED, is purpose-built fixed public theater seating that balances formal visual appeal with heavy-use functionality. Visually, the unit features rich blue woven fabric upholstery paired with warm reddish-brown finished wood elements, including polished solid hardwood armrest caps and perforated wood-grain modesty panels, creating a cohesive, polished look suited to formal public spaces. The ganged two-seat configuration connects via shared armrest brackets to maintain consistent, neat row alignment across installations, with round black powder-coated pedestal bases anchoring the structure for a clean, uncluttered floor line.
Constructed for long-term high-traffic use, the chair’s internal frame is made from phosphated, anti-rust treated cold-rolled steel with an electrostatic powder-coated finish, supporting pedestal bases secured permanently to floors with hex expansion bolts and covered by discreet plastic dust caps. Seating surfaces use anti-pilling, colorfast, breathable blue public-seating fabric over high-resilience cold-cure PU foam: 65 kg/m³ density foam 75mm thick cushions the seat, while 55 kg/m³ 95mm thick contoured foam at the back provides built-in lumbar support. Armrest supports are matte black powder-coated metal with integrated mounts for number plates, while front modesty panels use perforated wood-composite to enable acoustic diffusion.
Core practical functions center on quiet, user-centric operation: the tip-up seat uses a dual-spring damped mechanism that automatically returns to vertical when unoccupied, with a 3-second soft close that eliminates impact noise, and delivers 300 mm of minimum row passage clearance when folded to ease movement between rows. The perforated modesty panels diffuse reflected sound to reduce echo in large gathering spaces, and armrest supports are pre-configured to accept optional cup holders, writing tablets, or seat identification plates. Upholstery and foam can be specified with B1 flame-retardant treatment to meet public assembly code requirements.
This seating is ideal for permanent fixed-row installation in tiered or flat-floor venues including large auditoriums, lecture halls, conference centers, government assembly spaces, university lecture theaters, cinemas, performing arts venues, churches, and multi-purpose public assembly areas, with a formal aesthetic that aligns with official venue design and durable construction that stands up to daily high-frequency use.
For procurement, note that each two-seat set ships in two cartons, requires 40 minutes of assembly time per unit, and supports 135 set loads in a 20GP container at 85% space utilization. Buyers should specify B1 flame-retardant material upgrades if required by local public safety codes, and confirm accessory needs for cup holders, writing tablets, or number plates at the time of order to leverage pre-configured mounting points.

Two-Seat Ganged Blue Fabric Auditorium Chair with Perforated Wood Modesty Panels Specifications
