Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions per seat | 600 x 750 x 1080 mm | |
|---|---|---|
| Arm center-to-center width | 600 mm | |
| Seat height from floor | 460 mm | |
| Seat usable depth | 500 mm | |
| Armrest height from floor | 660 mm | |
| Backrest total height | 620 mm | |
| Inner seat width between armrests | 440 mm | |
| Minimum recommended row spacing | 1070 mm | |
| Side panel thickness | 15 mm | |
| Mounting footplate dimensions | 380 x 60 mm | |
| Headrest section height | 260 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended static user load capacity | 260 kg | |
|---|---|---|
| Seat cushion foam density | 60 kg/m³ | |
| Backrest foam density | 60 kg/m³ | |
| Seat foam thickness | 140 mm | |
| Backrest foam maximum thickness | 120 mm | |
| Fabric abrasion resistance | 50000 Martindale cycles | |
| Seat return noise level | 30 dB | |
| Unit net weight per seat | 28 kg | |
| Standard product warranty | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Woven public-seating fabric, flame-retardant and stain-resistant | |
|---|---|---|
| Seat cushion padding | Cold-cure high-resilience PU foam, 60kg/m³ density | |
| Backrest padding | Cold-cure high-resilience PU foam, 60kg/m³ density | |
| Side enclosures and arm caps | Oak veneer on 15mm hardwood multilayer board, matte polyurethane finish | |
| Cantilever support frame | Die-cast aluminum alloy ADC12, 5mm wall thickness, powder-coated silver finish | |
| Internal seat/arm frame | 2.0mm thick cold-rolled steel, welded and anti-rust treated | |
| Folding armrest mechanism | Zinc-plated steel hinge with aluminum end cap | |
| Seat return damper | Hydraulic damping cylinder for quiet tip-up operation | |
| Mounting hardware | Grade 8.8 expansion bolts for concrete floor fixation | |
| Exterior metal finish | Electrostatic polyester powder coating, scratch-resistant | |
| Seam stitch pitch | 8 stitches per inch | |
| Seat underside panel | Perforated wood composite panel with acoustic damping |
Adjustment / rotation / tilt / mobility / storage features
| Floor fixed installation | Cantilever base bolts directly to venue stepped or flat flooring | |
|---|---|---|
| Aisle-side folding armrest | Right armrest pivots upward 90 degrees to allow unobstructed aisle access | |
| Tip-up seat mechanism | Seat cushion rotates upward automatically when unoccupied to widen row clearance | |
| Damped quiet seat return | Hydraulic damper slows seat return to closed position to eliminate impact noise | |
| Fabric maintenance performance | Upholstery supports dry cleaning and stain removal for high-traffic use | |
| Modular row connection | Adjacent seats connect via shared side brackets to form continuous rows | |
| Ergonomic split backrest | Separate upper headrest and lower lumbar sections support upright seated posture | |
| Optional accessory compatibility | Supports retrofit installation of writing tablet, cup holder or aisle light | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Auditorium main hall seating | Fixed installation on sloped or flat floors for large performance and lecture events | |
|---|---|---|
| University lecture hall seating | Row-mounted configuration supports long-duration class and seminar use | |
| Government conference room seating | Formal wood side panel appearance matches official meeting space design requirements | |
| Cinema and performing arts venue seating | Tip-up seat and damped return support high-turnover audience flow | |
| Hospital conference/training room seating | Stain-resistant fabric and durable structure support frequent public use | |
| Courtroom formal seating | Fixed secure installation and professional appearance match judicial space requirements | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Furniture mechanical safety for seating | EN 12520:2015 | |
|---|---|---|
| Upholstered furniture fire resistance | EN 1021:2014 | |
| Public seating durability testing | EN 16139:2013 |
US and Canada office-furniture standards
| Office and public seating durability | ANSI/BIFMA X2017 |
|---|
Standards applicable to China-market projects
| Public seating structural safety | GB/T 3324 | |
|---|---|---|
| Upholstered furniture flame retardancy | GB 20286 | |
| Formaldehyde emission limit | GB 18580 |
This product must meet the following technical requirements: 1. Public seating structural safety: GB/T 3324; 2. Upholstered furniture flame retardancy: GB 20286; 3. Formaldehyde emission limit: GB 18580; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
