| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 550 x 420 mm | |
|---|---|---|
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total static load capacity | 300 kg | |
|---|---|---|
| Product net weight | 42 kg | |
| Seat foam density | 35 kg/m³ | |
| Fabric abrasion resistance (Martindale) | 30000 cycles | |
| Recommended number of users | 3 | |
| Leg static load per unit | 100 kg | |
| Expected service life (residential use) | 8 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery fabric | Textured woven polyester blend, light taupe color | |
|---|---|---|
| Seat padding core | High-resilience polyurethane foam, 120mm total thickness | |
| Internal support frame | Kiln-dried solid pine wood, 30mm structural thickness | |
| Support legs | Carbon steel with matte gunmetal electroplated finish, 80x80mm block profile | |
| Seat stitching | High-tenacity polyester thread, 30mm seam pitch | |
| Underside dust cover | Black non-woven polypropylene fabric, 1mm thickness | |
| Leg mounting plates | 2mm thick cold-rolled steel, pre-drilled for frame attachment | |
| Floor protection pads | 5mm thick adhesive felt pads, attached to leg bases | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Multi-seat contoured curved seating surface for 3 adults, no movable components | |
|---|---|---|
| Floor access clearance | 100mm unobstructed clearance under the seat, allows standard robot vacuum navigation | |
| Segmented contour support | Stitched segmented seat panels create subtle lumbar/thigh contour for extended sitting comfort | |
| Floor protection | Felt pads on all leg bases prevent scuffing and scratching on hard flooring surfaces | |
| Placement versatility | Curved organic shape fits curved entryways, bedroom footboards, or lounge waiting areas | |
| Structural stability | Six evenly spaced block legs eliminate wobble on level hard flooring surfaces | |
| Stain resistance base | Woven polyester fabric supports spot cleaning with mild detergent for daily maintenance | |
| Leg width (single block) | 80 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential entryway use | Curved form fits organic entry layouts, provides seating for shoe changing for households | |
|---|---|---|
| Bedroom end-of-bed placement | Low-profile design complements modern bed frames, provides dressing seating and linen storage surface | |
| Commercial lounge waiting areas | Durable woven fabric supports medium traffic in boutique lobbies, office breakout spaces | |
| Walk-in closet seating | Compact 550mm depth fits narrow closet aisles, provides seating for dressing and shoe selection | |
| Open plan living room accent seating | Organic curved shape acts as a standalone accent piece opposite sectional sofas |
EU Market Access Requirements* EN Standards
| Domestic seating safety | EN 12520:2015 Furniture - Strength, durability and safety - Requirements for domestic seating | |
|---|---|---|
| Upholstered furniture flammability | EN 1021:2014 Assessment of ignitability of upholstered furniture - Smouldering cigarette | |
| Furniture surface emission | EN 16516:2017 Construction products - Assessment of release of dangerous substances - VOC emission |
Standards applicable to China-market projects
| Seating structural safety | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Upholstery fabric safety | GB 18401National general safety technical code for textile products | |
| Furniture mechanical performance | GB/T 10357.3Test of mechanical properties of furniture - Strength and durability of chairs and stools | |
| Hardware corrosion resistance | GB/T 2007Determination of resistance to neutral salt spray for coatings |
This product must meet the following technical requirements: 1. Seating structural safety: GB/T 3324General technical requirements for wooden furniture; 2. Upholstery fabric safety: GB 18401National general safety technical code for textile products; 3. Furniture mechanical performance: GB/T 10357.3Test of mechanical properties of furniture - Strength and durability of chairs and stools; 4. Hardware corrosion resistance: GB/T 2007Determination of resistance to neutral salt spray for coatings; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
