Automatic mm / inch conversion · Core engineering specifications
| Overall bed dimensions | 1980 x 2230 x 1220 mm | |
|---|---|---|
| Recommended mattress size | 1800 x 2000 mm | |
| Headboard height | 1220 mm | |
| Headboard wing projection | 115 mm beyond each side rail | |
| Side rail height | 330 mm from floor to top of upholstered rail | |
| Foot rail height | 330 mm from floor to top edge | |
| Exposed leg height | 150 mm | |
| Under-bed clearance | 115 mm under the side rail | |
| Slat support width | 1800 mm clear inside side rails | |
| Slat support length | 2000 mm clear between headboard and foot rail | |
| Platform side rail thickness | 35 mm upholstered finished thickness | |
| Mattress support height | 300 mm from floor to slat surface | |
| Nightstand dimensions | 530 x 410 x 510 mm | |
| Nightstand drawer count | 2 drawers | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm |
Net weight / load capacity / users / durability
| Bed static load capacity | 454 kg | |
|---|---|---|
| Recommended occupant capacity | 2 adults | |
| Net weight | 59 kg | |
| Slat count | 14 slats | |
| Slat spacing | 80 mm clear gap | |
| Center support legs | 3 legs along one central rail | |
| Recommended mattress thickness | 457 mm | |
| Minimum mattress thickness for headboard support | 254 mm | |
| Perimeter rail static point load | 90 kg per rail section | |
| Nightstand top load | 25 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Matte gray woven-look fabric with padded face and vertical channel seams | |
|---|---|---|
| Headboard internal panel | 25 mm engineered-wood or kiln-dried hardwood frame panel | |
| Headboard foam | 20 mm polyurethane padding on face and wings | |
| Side and foot rails | Gray upholstered engineered-wood rails with 15 mm visible padding | |
| Support slats | 9 mm bentwood or laminated poplar slats in fabric-covered retainers | |
| Center support rail | Rectangular steel or hardwood center rail with floor legs | |
| Bed legs | 25 mm diameter black powder-coated metal tapered legs | |
| Mounting hardware | M8 blackened steel bolts, barrel nuts and corner brackets | |
| Nightstand exterior | Matching gray upholstered or laminated engineered-wood case | |
| Nightstand drawer slides | Side-mounted 35 mm two-section drawer slides | |
| Nightstand legs | Black powder-coated metal angled legs | |
| Nightstand handles | 128 mm centered black bar pulls |
Adjustment / rotation / tilt / mobility / storage features
| Platform support | 14 slats mount across the frame and support the mattress directly without a box spring | |
|---|---|---|
| Center beam support | One longitudinal center rail transfers load to 3 floor legs, reducing slat deflection | |
| Wingback enclosure | Curved side wings extend beyond the headboard face and visually contain pillows at both ends | |
| Channel-tufted headboard | Three padded vertical channels form the backrest face and maintain a smooth tailored surface | |
| Low-profile entry | 300 mm slat height and 330 mm rail height give a modern low seating height | |
| Knock-down assembly | Headboard, side rails, foot rail, slat rolls and legs bolt together for flat-pack shipping | |
| Noise control | Slat retainers and bolted corner joints are specified with EVA contact pads to reduce metal or wood movement | |
| Mattress retention | Upholstered side and foot rails contain the mattress perimeter and limit lateral sliding | |
| Under-bed access | 115 mm ground clearance permits robotic vacuum access and limited air circulation | |
| Nightstand storage | Two stacked drawers provide separate storage for bedside items and personal accessories | |
| Vertical seam headboard | Two seams divide the padded face into 3 vertical backrest panels | |
| Noise-reduction contact system | EVA pads isolate slats, corner brackets and leg plates to suppress frame movement noise |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Main bedroom | Suitable for a 1800 mm two-adult mattress in homes or serviced apartments where wingback styling is required. | |
|---|---|---|
| Hotel guest room | Pairs a 454 kg static-load bed with a compact two-drawer nightstand for overnight guest storage. | |
| Modern residential suite | Low 300 mm platform height and gray woven finish fit contemporary gray or neutral interiors. | |
| Small bedside zone | 530 mm wide nightstand fits beside the wing without blocking room circulation or the bed leg. | |
| Robotic-vacuum household | 115 mm under-bed clearance supports routine cleaning under the upholstered rails. | |
| Knock-down furnishing project | Flat-pack 3-carton bed suits multi-unit delivery and on-site assembly in apartments. | |
| Reading-in-bed use | Padded 1220 mm headboard and side wings provide back and pillow support for two users. |
EU Market Access Requirements* EN Standards
| EN 1725:1998 | Domestic bedding safety, strength and durability requirements applicable to bedsteads. | |
|---|---|---|
| EN 12521:2015 | Furniture strength, durability and safety requirements for domestic beds. |
Standards applicable to China-market projects
| GB/T 3324-2024 | General technical requirements for wooden furniture, applicable to frame strength, dimensions and workmanship. | |
|---|---|---|
| GB/T 3325-2017 | Metal furniture general technical requirements, applicable to coated steel legs and support rails. | |
| GB 18584-2001 | Indoor decorative materials limit formaldehyde emission from wood-based furniture components. | |
| GB/T 10357.6-2013 | Furniture test for single-bed strength and durability, applicable to slats, rails and legs. | |
| GB/T 10357.7-2013 | Furniture stability testing, applicable to the free-standing platform frame. |
This product must meet the following technical requirements: 1. GB/T 3324-2024: General technical requirements for wooden furniture, applicable to frame strength, dimensions and workmanship.; 2. GB/T 3325-2017: Metal furniture general technical requirements, applicable to coated steel legs and support rails.; 3. GB 18584-2001: Indoor decorative materials limit formaldehyde emission from wood-based furniture components.; 4. GB/T 10357.6-2013: Furniture test for single-bed strength and durability, applicable to slats, rails and legs.; 5. GB/T 10357.7-2013: Furniture stability testing, applicable to the free-standing platform frame.; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
