Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2800 x 2200 x 750 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Desktop edge band thickness | 2 mm | |
| Central seated knee clearance width | 800 mm | |
| Central seated knee clearance height | 650 mm | |
| Cantilever base wall thickness | 3 mm | |
| Polished stainless steel trim width | 30 mm | |
| Burl wood accent panel thickness | 18 mm | |
| Cable grommet diameter | 80 mm | |
| Under-desk cable tray depth | 150 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 130 kg | |
|---|---|---|
| Drawer slide rated static load per drawer | 45 kg | |
| Drawer slide durability cycle count | 50000 cycles | |
| Door hinge durability cycle count | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Suggested maximum user weight for seated use | 150 kg | |
| Product net weight | 260 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main work surface | High-gloss light sintered stone panel | |
|---|---|---|
| Decorative facade panels | Burl wood veneer over MDF core | |
| Side support panels | Brushed gunmetal finished steel | |
| Edge trim elements | Polished 304 stainless steel | |
| Internal support frame | Reinforced square steel tube | |
| Drawer box construction | 18mm thick E1 grade MDF with soft-close edges | |
| Hardware components | Zinc alloy lock cores and steel guide rails | |
| Surface coating on metal parts | Epoxy powder coat with scratch-resistant clear topcoat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Dual 80mm desk grommets with under-desk steel cable tray | |
|---|---|---|
| Integrated storage drawers | Three lockable soft-close drawers on full-extension ball-bearing slides | |
| Cantilever base design | Asymmetric floor-sweeping steel support with open central knee bay | |
| Modesty panel integration | Full-width gunmetal metal front panel below desktop | |
| Optional integrated power unit | 3 AC outlets + 2 USB charging ports + 1 RJ45 data port | |
| Matching storage compatibility | Pre-drilled alignment points for matching return/credenza units | |
| Surface maintenance feature | Stain-resistant non-porous high-gloss top finish | |
| Locking storage mechanism | Centralized key lock system securing all drawer compartments | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Primary use for CEO, president or senior leadership in corporate headquarters | |
|---|---|---|
| High-end reception meeting space | Suitable for small in-office meetings with 3additional visitors | |
| Bespoke luxury home office | Applicable for high-net-worth residential workspaces with premium interior design | |
| Boardroom ancillary workspace | Works as a supporting work surface adjacent to main conference table | |
| Designer office suite | Pairs with matching tall display storage cabinet and executive leather chair | |
| Commercial furniture procurement | Target product for Class A office building tenant improvement projects |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions | |
|---|---|---|
| EN 527-2:2016 | Office work tables - Part 2: Mechanical safety requirements | |
| EN 13722:2004 | Furniture - Test methods for surfaces - Assessment of surface resistance to abrasion | |
| EN 71-3:2019 | Safety of toys - Migration of certain elements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Tests for structural durability and safety | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Tests for structural durability | |
| ANSI/BIFMA e3-2019 | Furniture Sustainability Standard |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 4897.3-2003 | Particleboard for furniture use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 3325-2017: General technical requirements for metal furniture; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 4897.3-2003: Particleboard for furniture use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
