Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 2200 x 760 mm | |
|---|---|---|
| Main desktop depth | 900 mm | |
| Side return width | 1200 mm | |
| Side return depth | 600 mm | |
| Desktop thickness | 38 mm | |
| Knee clearance width | 800 mm | |
| Knee clearance height | 650 mm | |
| Leather writing pad dimensions | 1200 x 500 mm | |
| Cable grommet diameter | 60 mm | |
| Edge band thickness | 3 mm | |
| Pedestal base height | 720 mm | |
| Drawer front panel thickness | 18 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total desktop static load capacity | 204 kg | |
|---|---|---|
| Drawer slide cycle rating | 50000 cycles | |
| Net weight reference | 204 kg | |
| Finish abrasion resistance | 2000 cycles | |
| Leveling glide adjustment range | 15 mm | |
| Warranty period | 10 years | |
| Available color options | 3 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | High-density MDF core | |
|---|---|---|
| Desktop finish | Red mahogany wood veneer with high-gloss lacquer | |
| Central writing surface | Black top-grain leather writing pad | |
| Pedestal frame and panels | Solid wood trim with veneered MDF panels | |
| Edge treatment | Rounded polished solid wood edge banding | |
| Drawer slides | Cold-rolled steel ball-bearing full-extension slides | |
| Cable grommets | ABS plastic with brushed metal cover | |
| Leveling glides | Nylon base with steel threaded stem | |
| Drawer locks | Zinc alloy keyed cam locks | |
| Hardware finish | Matte black hardware | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Two 60mm desktop grommets with under-desk cable tray | |
|---|---|---|
| Storage configuration | Four general supply drawers, two locking legal/letter file drawers | |
| Drawer operation | Full-extension soft-close ball bearing slides | |
| Desk leveling | Eight adjustable nylon leveling glides at base corners | |
| Work surface layout | L-shaped dual-zone layout with main work area and side return | |
| Writing surface function | Leather pad provides non-slip, scuff-resistant writing and mouse surface | |
| Drawer locking | Central keyed lock secures all file and supply drawers | |
| Assembly structure | Three-section knockdown construction for transport | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits 25sqm private executive offices for senior management use | |
|---|---|---|
| Corporate boardroom auxiliary workspace | Serves as supplemental workspace adjacent to conference tables | |
| Government/official office space | Formal red wood finish matches traditional official office design standards | |
| High-end home executive office | Suitable for luxury home offices requiring traditional formal furnishing | |
| Recommended chair pairing | High-back leather executive chair with 700mm wide seat | |
| Matching storage configuration | Pairs with full-height red wood filing cabinets as seen in background |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables safety and strength requirements, applicable to structural load testing | |
|---|---|---|
| EN 527-2:2016 | Office work tables dimensional and mechanical safety requirements for seated use | |
| EN 13722:2004 | Furniture strength and durability test for storage units integrated into desks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for integrated pedestal drawer performance and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to desk structural performance | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to substrate material performance | |
| GB 18584-2001 | Indoor decorating material limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to desk structural performance; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to substrate material performance; 3. GB 18584-2001: Indoor decorating material limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
