Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 2400 x 1100 x 762 mm | |
|---|---|---|
| Desktop thickness | 50 mm | |
| Return side width | 1600 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance width | 1200 mm | |
| Cable grommet diameter | 76 mm | |
| Storage pedestal height | 712 mm | |
| Support leg diameter | 120 mm | |
| Edge banding thickness | 2 mm | |
| Base plinth accent trim height | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 160 kg | |
|---|---|---|
| Drawer slide static load rating | 45 kg | |
| Drawer slide cycle rating | 50000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Cable grommet cable capacity | 10 cords | |
| Unit net weight range | 120 kg | |
| Adjustable floor leveler adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main worktop | E1-grade engineered wood substrate with matte woodgrain melamine laminate finish | |
|---|---|---|
| Storage pedestal panels | Low-formaldehyde engineered wood with light taupe matte paint finish | |
| Desktop edge banding | 2mm thick ABS impact-resistant edge banding | |
| Right support leg | Powder-coated cylindrical steel leg with integrated floor leveler | |
| Base plinth accent trim | Brushed metallic gold-tone ribbed decorative trim | |
| Cable grommet | Zinc alloy flush-mount cable management grommet with brush insert | |
| Drawer hardware | Cold-rolled steel ball-bearing full-extension drawer slides | |
| Base structural frame | 1.2mm thick powder-coated steel internal support frame | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Cable management | Single flush grommet routes power, data and peripheral cords from work surface to under-desk area | |
|---|---|---|
| Storage configuration | Left enclosed pedestal with two upper storage compartments and one lower file drawer | |
| Floor leveling | Integrated adjustable levelers on base and support leg compensate for uneven office flooring | |
| Work surface layout | L-shaped layout provides primary writing zone and secondary peripheral/meeting zone | |
| Drawer operation | Full-extension slides allow complete access to drawer contents without overhang obstruction | |
| Surface protection | Scratch, stain and moisture resistant laminate finish resists everyday office wear and spills | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Sized for dedicated senior management private workspaces with spacious work area | |
|---|---|---|
| Corporate CEO/Director workspace | Premium aesthetic and integrated storage suit senior leadership office requirements | |
| High-end home office | Sophisticated two-tone finish works for luxury residential executive home office setups | |
| Boardroom auxiliary workspace | Can be used as a meeting room side desk for document preparation during sessions | |
| Recommended paired furniture | Pairs with high-back executive leather chair, matching wall storage bookcase and office visitor seating |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable for structural performance verification | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units strength and durability requirements, applicable for pedestal testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for strength, durability and functional performance of pedestal components |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural and finish quality inspection | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance | |
| GB/T 4897.3-2003 | Particleboard specifications for furniture use, applicable for panel substrate verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural and finish quality inspection; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor air quality compliance; 3. GB/T 4897.3-2003: Particleboard specifications for furniture use, applicable for panel substrate verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
