Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1800 x 750 mm | |
|---|---|---|
| Main desktop depth | 800 mm | |
| Side return storage cabinet depth | 600 mm | |
| Desktop panel thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Seated knee clearance height | 620 mm | |
| Seated knee clearance width | 1200 mm | |
| Support leg panel thickness | 50 mm | |
| Modesty panel height | 450 mm | |
| Cable grommet diameter | 80 mm | |
| Side return cabinet height | 700 mm | |
| Rounded desktop corner radius | 50 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 100 kg | |
|---|---|---|
| Drawer open/close cycle rating | 50000 cycles | |
| Finish abrasion resistance rating | 2000 cycles | |
| Net product weight | 120 kg | |
| Recommended user weight capacity | 150 kg | |
| Manufacturer warranty period | 5 years | |
| Available color variants | 5 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E0 grade high-density fiberboard | |
|---|---|---|
| Desktop finish | Matte baking varnish coating | |
| Edge banding | 2mm thick anti-collision PVC trim | |
| Support and modesty panels | E1 grade medium-density fiberboard | |
| Side return cabinet exterior | Two-tone matte laminate over MDF | |
| Drawer hardware | Cold-rolled steel soft-close full-extension slides | |
| Base trim accents | Powder-coated steel feet | |
| Cable grommet | ABS plastic recessed port | |
| Internal drawer components | Zinc-plated steel hardware with soft-close dampers | |
| Cabinet door panel | 18mm thick MDF with matching matte finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Ergonomic fixed work height | 750 mm desk surface height optimized for standard office chair seat heights | |
|---|---|---|
| Integrated cable management | Recessed desktop grommet routes power and data cables under work surface | |
| Left-side return storage | Enclosed floor-standing cabinet provides document and office supply storage | |
| Soft-close drawer operation | Damped slides close silently without slamming for quiet office use | |
| Anti-collision rounded edges | Curved corner design reduces impact injury risk during office movement | |
| Central knee clearance opening | 1200mm wide open well supports unobstructed seated leg movement | |
| Modesty panel coverage | Full front panel blocks leg visibility for professional office presentation | |
| Lockable file storage option | Optional locking mechanism secures confidential documents in return cabinet drawers | |
| Floor leveler adjustment | Adjustable feet at base compensate for uneven office flooring surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for manager, director or C-suite individual workspaces with professional aesthetic | |
|---|---|---|
| Open-plan manager workstation | Functions as a dedicated senior staff work point in semi-open office layouts | |
| Conference side work area | Provides secondary work and storage space adjacent to small meeting rooms | |
| Commercial office procurement | Designed for 8+ year daily commercial use in corporate or government workplaces | |
| Dual-monitor workstation setup | 800mm depth supports multi-monitor arrangements with sufficient rear clearance | |
| Visitor interaction layout | Desk front orientation supports short face-to-face meetings across work surface | |
| Document-heavy work roles | Integrated return storage supports filing needs for administrative or management roles |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial workplace use | |
|---|---|---|
| EN 13722:2004 | Furniture storage units strength and durability requirements for side cabinet | |
| EN 12521:2015 | Furniture hardware drawer slide durability and load performance requirements |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for safety, durability and structural performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for cabinet and drawer performance validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, applicable to E0/E1 panel selection | |
| GB/T 4897.3-2003 | Performance requirements for particleboard used in furniture structural components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, applicable to E0/E1 panel selection; 3. GB/T 4897.3-2003: Performance requirements for particleboard used in furniture structural components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
