Automatic mm / inch conversion · Core engineering specifications
| overall footprint | 2000 x 1600 x 780 mm | |
|---|---|---|
| main worktop depth | 900 mm | |
| side return cabinet dimensions | 1200 x 600 x 650 mm | |
| worktop thickness | 50 mm | |
| edge banding thickness | 2 mm | |
| knee clearance height | 650 mm | |
| knee clearance width | 1200 mm | |
| desk grommet diameter | 80 mm | |
| side panel thickness | 25 mm | |
| plinth base height | 100 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| worktop static load capacity | 300 kg | |
|---|---|---|
| drawer slide load rating | 45 kg | |
| drawer slide cycle rating | 50000 cycles | |
| cabinet hinge cycle rating | 80000 cycles | |
| laminate surface abrasion resistance | 2000 cycles | |
| product net weight | 165 kg | |
| recommended user weight capacity | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| main worktop | 25mm MDF core with thermally fused warm wood grain laminate | |
|---|---|---|
| accent modesty panel | 18mm particleboard core with matte beige melamine finish | |
| side return cabinet body | 25mm engineered wood with matching wood grain laminate | |
| edge treatment | 2mm thick matching PVC edge banding with rounded soft corners | |
| plinth base trim | Matte beige PVC wrapped engineered wood kickboard | |
| cable grommet port | ABS plastic housing with integrated AC power and USB charging ports | |
| side port panel | ABS plastic frame with dual power/data outlet modules | |
| internal hardware | Zinc-plated steel screws, cam locks and connecting fittings | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| work surface layout | Fixed L-shaped layout with main writing surface and attached left storage return | |
|---|---|---|
| power and data access | Dual integrated port panels: one embedded in worktop, one on side cabinet exterior | |
| cable management | Under-desk cable tray routing from grommets to rear desk exit points | |
| storage configuration | Enclosed cabinet storage in side return with internal drawer and shelf space | |
| edge safety design | Full rounded soft corners on all worktop and cabinet edges to reduce impact injury | |
| fixed height design | Non-adjustable fixed work surface height set at seated ergonomic office position | |
| base stability | Full plinth base support across main desk and return cabinet for zero wobble | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| private executive office | Suited for CEO, director or senior manager private offices, providing ample work and storage space | |
|---|---|---|
| corporate headquarters | Appropriate for high-spec corporate workspaces requiring a polished professional aesthetic | |
| boardroom ancillary space | Usable as a supporting work surface in meeting or boardroom preparation areas | |
| recommended seating pairing | Pairs with high-back leather or faux leather executive office chairs of standard seat height | |
| work device support | Supports multiple monitors, laptop, desk phone and office accessories across L-shaped surface |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables: Safety and strength requirements, applicable to desk stability and load testing | |
|---|---|---|
| EN 527-2:2002+A1:2019 | Office worktables: Dimensional requirements for ergonomic seated work surfaces | |
| EN 14073-2:2004 | Office storage furniture: Safety requirements for cabinet pedestals integrated into desks | |
| EN 12720:2009+A1:2013 | Furniture surface resistance to cold liquids, applicable to laminate worktop finish performance |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to panel construction and dimensional tolerances | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to structural panel core material requirements | |
| GB/T 11718-2009 | Medium density fiberboard (MDF) for furniture, applicable to worktop core material requirements | |
| GB 28007-2011 | Office furniture structural safety requirements, applicable to edge radii and stability testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to panel construction and dimensional tolerances; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to structural panel core material requirements; 3. GB/T 11718-2009: Medium density fiberboard (MDF) for furniture, applicable to worktop core material requirements; 4. GB 28007-2011: Office furniture structural safety requirements, applicable to edge radii and stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
