Automatic mm / inch conversion · Core engineering specifications
| overall desk dimensions | 2600 x 2000 x 750 mm | |
|---|---|---|
| main desktop thickness | 25 mm | |
| modesty panel thickness | 16 mm | |
| side return width (each wing) | 600 mm | |
| knee clearance width | 1200 mm | |
| knee clearance height | 650 mm | |
| knee clearance depth | 600 mm | |
| desktop edge band thickness | 2 mm | |
| support column cross-section | 180 x 180 mm | |
| cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| desktop static load capacity | 120 kg | |
|---|---|---|
| drawer slide load rating (if fitted) | 45 kg | |
| drawer slide cycle rating | 50000 cycles | |
| hinge cycle rating (if fitted) | 80000 cycles | |
| surface abrasion resistance | 2000 cycles | |
| desk net weight range | 180 kg | |
| recommended maximum user weight at work surface | 150 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| desktop substrate | E0-grade MDF/particle board core | |
|---|---|---|
| desktop finish | Matte dark grey melamine facing | |
| front modesty panel | Vertical ribbed off-white MDF with matching melamine finish | |
| corner support columns | Two-tone off-white and dark grey engineered wood with rounded edge trim | |
| edge banding | 2mm thick color-matched ABS edging | |
| internal support frame | Powder-coated rectangular steel tube understructure | |
| cable management components | ABS plastic grommets and steel cable tray | |
| drawer hardware (if fitted) | Cold-rolled steel three-section ball-bearing slides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| cable management | Dual desktop grommets with under-desk cable tray to route power and data cords | |
|---|---|---|
| storage integration | Pre-drilled mounting points for matching mobile file pedestal under side returns | |
| seated work access | Central knee opening provides unobstructed legroom for executive office chair | |
| surface durability | Stain, water and scratch resistant melamine surface for daily office use | |
| leveling adjustment | Adjustable feet on base to stabilize desk on uneven office flooring | |
| modesty coverage | Full-height front ribbed panel blocks knee view for office privacy | |
| extended work surface | Dual symmetric side returns provide additional space for peripherals and documents | |
| locking storage compatibility | Compatible with lockable drawer pedestal for secure document storage | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| private executive office | Primary use for CEO/manager private office, supports daily desk work and meetings | |
|---|---|---|
| high-end corporate workspace | Suitable for premium corporate headquarters and grade-A office buildings | |
| paired matching cabinetry | Designed for use with matching full-height back wall bookcase and storage units | |
| single user dedicated workstation | Optimized for single senior employee use with extended surface for documents and peripherals | |
| visitor meeting at desk | Wide front profile supports short seated visitor meetings across the desk surface | |
| formal office reception for senior staff | Suitable for formal meetings with internal staff and visiting clients | |
| office carpet or hard flooring installation | Leveling feet support installation on both low-pile carpet and hard commercial flooring |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Part 1: Dimensions, applicable for work surface height and clearance verification | |
|---|---|---|
| EN 527-2:2002 | Office work tables - Part 2: Mechanical safety requirements for structural stability | |
| EN 13722:2004 | Furniture - Assessment of surface resistance to abrasion for desktop finish performance | |
| EN 717-1:2004 | Wood-based panels - Formaldehyde release testing for indoor air quality compliance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products standard, applicable for structural load and durability testing for commercial office use | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units standard, applicable if fitted with integrated drawer or cabinet components | |
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and environmental impact assessment |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for desk panel and structural integrity checks | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for substrate formaldehyde emission and strength verification | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture | |
| GB/T 1931-2009 | Wood moisture content determination method for furniture production quality control |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for desk panel and structural integrity checks; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for substrate formaldehyde emission and strength verification; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; 4. GB/T 1931-2009: Wood moisture content determination method for furniture production quality control; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
