| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| overall dimensions | 2800 x 2000 x 760 mm | |
|---|---|---|
| main desktop work surface | 2200 x 900 mm | |
| left side return cabinet dimensions | 1800 x 600 x 650 mm | |
| desktop thickness | 50 mm | |
| seated knee clearance height under main desk | 620 mm | |
| seated knee clearance width under main desk | 1200 mm | |
| cable grommet diameter | 80 mm | |
| gold edge trim thickness | 2 mm | |
| modesty panel height | 350 mm | |
| side cabinet side panel thickness | 18 mm | |
| base plinth height | 50 mm | |
| diamond texture panel strip height | 80 mm | |
| edge band thickness | 1 mm | |
| right support leg cross section | 100 x 100 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| desktop static load capacity | 150 kg | |
|---|---|---|
| drawer slide cycle rating | 50000 cycles | |
| net product weight | 250 kg | |
| maximum seated user capacity | 1 | |
| finish abrasion resistance | 2000 cycles | |
| adjustable foot leveler adjustment range | 15 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| desktop substrate | 50mm CARB P2 compliant engineered wood | |
|---|---|---|
| cabinet body panels | 18mm E0 grade engineered wood | |
| desktop edge trim | Polished gold-toned zinc alloy | |
| front modesty panel accent | Textured diamond-pattern ABS/engineered wood | |
| support leg | Engineered wood with matching dark wood veneer | |
| drawer slides and hardware | Cold-rolled steel with zinc plating |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| cable management grommet | 80mm diameter desktop port for routing monitor and laptop cables | |
|---|---|---|
| attached side storage cabinet | Enclosed storage with three drawers and one door compartment | |
| lockable storage | Central keyed lock securing all desk drawers and cabinet door | |
| fixed seated work height | 760mm standard office desk height optimized for ergonomic seated use |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| executive private office | Suitable for CEO, director or manager private workspaces with luxury professional aesthetic | |
|---|---|---|
| corporate board meeting side office | Functions as a secondary high-end work surface in meeting room ancillary spaces |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work desk dimensional and safety performance requirements for commercial use | |
|---|---|---|
| EN 12521:2015 | Strength, durability and stability requirements for non-domestic office furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products safety and performance standard for commercial office applications |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to wooden office furniture products | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit requirement for engineered wood panels used in desks | |
| GB/T 4897.3-2015 | Performance standard applicable to particleboard substrates for office furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to wooden office furniture products; 2. GB 18580-2017: Formaldehyde emission limit requirement for engineered wood panels used in desks; 3. GB/T 4897.3-2015: Performance standard applicable to particleboard substrates for office furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
