| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2400 x 1800 x 750 mm | |
|---|---|---|
| Desktop panel thickness | 25 mm | |
| Main desktop work depth | 900 mm | |
| Side return work depth | 600 mm | |
| Under-desk knee clearance height | 620 mm | |
| Under-desk knee clearance width | 780 mm | |
| PVC edge band thickness | 2 mm | |
| Cable grommet diameter | 80 mm | |
| Left pedestal cabinet width | 700 mm | |
| Right pedestal cabinet width | 550 mm | |
| Modesty panel thickness | 16 mm | |
| Desktop corner radius | 30 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide static load per drawer | 45 kg | |
| Drawer slide cycle durability | 50000 cycles | |
| Hinge cycle durability | 80000 cycles | |
| Surface abrasion resistance | 2000 cycles | |
| Product net weight | 160 kg | |
| Recommended user weight capacity | 136 kg | |
| Warranty period | 5 years | |
| Available finish variants | 3 | |
| Top Static Load Reference | 150 kg uniformly distributed |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop core | E1 grade engineered wood board | |
|---|---|---|
| Desktop finish | Dark wood grain melamine laminate | |
| Accent panels | Light taupe matte engineered wood panels | |
| Modesty panel front | Horizontal ribbed engineered wood panel | |
| Edge banding | 2 mm PVC edge trim | |
| Left cabinet hardware | Ventilated steel grille panel | |
| Drawer slides | Cold-rolled steel ball-bearing slides | |
| Door hinges | Cold-rolled steel soft-close hinges | |
| Leveling glides | Nylon base adjustable glides | |
| Structural support beams | 1.5 mm thick powder-coated steel | |
| Cable grommets | ABS plastic cable ports | |
| Drawer handles | Matte black recessed alloy handles |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Dual desktop grommets and under-desk steel tray | |
|---|---|---|
| Left pedestal storage | Locking drawer stack plus ventilated CPU compartment | |
| Right pedestal storage | Two lockable file drawers with full-extension slides | |
| Modesty panel function | Fixed full-width ribbed panel | |
| Leveling adjustment | 15 mm height adjustment via base glides | |
| Ventilation design | Vertical slot vents on left cabinet panel | |
| Locking system | Centralized key lock for all storage drawers | |
| Storage configuration | Closed cabinet doors plus open adjustable shelving on matching bookcase | |
| Desktop surface design | Rounded safety edges with contrasting light trim | |
| Assembly configuration | Knock-down flat-pack construction for on-site assembly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary placement for CEO, manager or director workspaces | |
|---|---|---|
| Senior management open office zone | Suitable for enclosed team leader workstations | |
| Boardroom ancillary workspace | Used as supporting work surface adjacent to meeting rooms | |
| High-end home office | Ideal for luxury residential home office setups | |
| Configuration recommendation | Pairs with matching high-back leather executive chair and wall bookcase | |
| Equipment compatibility | Accommodates dual monitors, desktop computer and printer |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office work tables - Safety and strength requirements | |
|---|---|---|
| EN 13722:2004 | Office furniture - Storage units - Safety requirements | |
| EN 14073-2:2004 | Office furniture - Storage furniture - Safety requirements | |
| EN 71-3:2019 | Migration of certain elements for furniture surfaces |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk Products - Performance and safety standard | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage Units - Performance and safety standard | |
| ANSI/BIFMA M7.1-2020 | Furniture VOC emissions test method |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels | |
| GB/T 10357.1-2013 | Furniture mechanical performance test for tables |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture; 2. GB/T 4897.3-2003: Particleboard for furniture use; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels; 4. GB/T 10357.1-2013: Furniture mechanical performance test for tables; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
