Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Finished Top Thickness | 50 mm | |
|---|---|---|
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desk top static load capacity | 150 kg | |
|---|---|---|
| Side pedestal storage static load per compartment | 40 kg | |
| Recommended seated user weight capacity | 130 kg | |
| Desk net weight (without hutch) | 180 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desk top main surface | 25mm thick walnut-woodgrain E1 grade melamine faced chipboard | |
|---|---|---|
| Desk center writing pad | Beige matte scratch-resistant laminate panel | |
| Cabinet side panels and door fronts | Off-white matte melamine panel with wood-grain edge banding | |
| Modesty panel front | Beige vertically fluted leather-look decorative panel | |
| Cable management grommet | Brushed aluminum alloy recessed cable tray | |
| Accent lighting components | 3000K warm white LED strip lights with aluminum channel housing |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management system | Recessed center grommet routes power and data cables from desk top to under-desk space | |
|---|---|---|
| Ambient accent lighting | Warm LED strips illuminate under-desk front and hutch open shelves for visual comfort | |
| Integrated storage pedestals | Two fixed side cabinets provide closed storage for documents and office supplies, central open knee space | |
| Matching back storage unit | Combination of closed door cabinets and open display shelves for office books and decor |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Executive private office | Provides dedicated large work surface and integrated storage for senior management roles | |
|---|---|---|
| Manager workspaces | Sufficient work area and storage for daily administrative and leadership tasks |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
