Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2400 x 2150 x 760 mm | |
|---|---|---|
| Main worktop depth | 900 mm | |
| Side return length | 1600 mm | |
| Worktop thickness | 25 mm | |
| Edge band thickness | 2 mm | |
| Knee clearance height | 660 mm | |
| Knee clearance width | 800 mm | |
| Metal base panel thickness | 1.5 mm | |
| Cable grommet diameter | 80 mm | |
| Worktop overhang | 30 mm | |
| Fluted panel section width | 1200 mm | |
| Return worktop depth | 600 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 150 kg | |
|---|---|---|
| Drawer slide load rating | 45 kg | |
| Drawer slide cycle life | 50000 cycles | |
| Door hinge cycle life | 100000 cycles | |
| Recommended user weight | 150 kg | |
| Net product weight | 135 kg | |
| Standard warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop substrate | 25mm E1-grade MDF | |
|---|---|---|
| Worktop finish | Walnut wood grain veneer | |
| Base frame material | 1.5mm cold-rolled steel | |
| Front decorative panel | Vertically fluted steel panel | |
| Edge treatment | 2mm PVC edge banding | |
| Drawer internal construction | E1-grade particleboard | |
| Hardware material | Zinc-plated steel hardware | |
| Leveling feet | Nylon-padded adjustable steel feet | |
| Cable grommet | Brushed ABS plastic grommet | |
| Base paint finish | Matte powder coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Integrated storage layout | 2 utility drawers, 1 hanging file drawer, 1 closed cabinet | |
|---|---|---|
| Cable management system | 1 top recessed cable grommet, under-desk cable tray | |
| Floor leveling adjustment | 6 adjustable leveling feet | |
| Return work surface | Fixed auxiliary side return surface | |
| Drawers with soft-close | Soft-close drawer slides | |
| Door soft-close mechanism | Concealed soft-close hinges | |
| Fixed work height | Fixed 760mm seated work height | |
| Rounded corner design | Radius 20mm rounded corners on worktop and base | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Suitable for CEO, director or manager private offices, provides generous work and storage space | |
|---|---|---|
| Manager work area | Appropriate for middle management workspaces, supports document processing and computer work | |
| High-end reception office | Fits luxury reception or meeting office spaces, provides premium professional appearance | |
| Recommended matching chair | Pairs with mid-back or high-back ergonomic executive chairs with 480 mm seat height | |
| Single user configuration | Designed for one primary seated user, return surface supports guest interaction or auxiliary equipment | |
| Commercial office interiors | Suits modern, light-luxury commercial interior design schemes with metal and wood material palettes |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to structural load testing | |
|---|---|---|
| EN 527-2:2002 | Office worktables dimensional safety requirements, applicable to knee clearance dimensions | |
| EN 13722:2004 | Office furniture storage units performance requirements, applicable to drawer and cabinet durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, applicable to static load, stability and durability testing for office desks |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to desk structural performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade requirement for all panel components | |
| GB/T 4897.3-2003 | Particleboard specification for furniture use, applicable to drawer and cabinet panels | |
| GB/T 11718-2009 | Medium density fiberboard specification, applicable to worktop substrate performance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to desk structural performance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade requirement for all panel components; 3. GB/T 4897.3-2003: Particleboard specification for furniture use, applicable to drawer and cabinet panels; 4. GB/T 11718-2009: Medium density fiberboard specification, applicable to worktop substrate performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
