Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2800 x 2200 x 750 mm | |
|---|---|---|
| Main worktop depth | 800 mm | |
| Side return cabinet depth | 600 mm | |
| Desktop thickness | 25 mm | |
| Bevelled user edge overhang | 50 mm | |
| Knee clearance height | 650 mm | |
| Knee clearance width | 1200 mm | |
| Modesty panel slat width | 30 mm | |
| Ventilation slot length on return cabinet | 150 mm | |
| Edge banding thickness | 2 mm | |
| Base plinth height | 50 mm | |
| Cable grommet diameter | 80 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Desktop static load capacity | 300 kg | |
|---|---|---|
| Drawer slide load rating | 45 kg | |
| Drawer slide cycle life | 50000 cycles | |
| Cabinet hinge cycle life | 80000 cycles | |
| Net weight | 160 kg | |
| Recommended user weight capacity | 150 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E1 grade MDF with dark brown woodgrain melamine veneer | |
|---|---|---|
| Cabinet and frame panels | E1 grade particleboard with taupe matte melamine finish | |
| Modesty panel | Vertical fluted engineered wood slats, taupe finish | |
| Edge banding | 2mm thick impact-resistant PVC edging | |
| Hardware components | Cold-rolled steel drawer slides, steel hinges, zinc-plated connectors | |
| Leveling glides | Nylon base adjustable glides under plinth | |
| Ventilation grille | Cut engineered wood panel with horizontal slots | |
| Cable grommets | ABS plastic flush-mount cable ports | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Fixed height work surface | 750 mm working height optimized for standard executive office chairs | |
|---|---|---|
| Right-side integrated storage return | Combines open CPU bay with ventilated panels and enclosed drawer/cabinet storage | |
| Cable management system | Undermount cable tray plus desktop grommets route power/data cords out of sight | |
| Front fluted modesty panel | Full-height vertical slat panel blocks view of under-desk area for privacy | |
| Bevelled ergonomic front edge | Angled desktop edge reduces forearm pressure during extended work sessions | |
| Ventilated equipment storage | Vertical slotted vents on return cabinet allow airflow for housed PC/IT equipment | |
| Lockable storage option | Drawer and cabinet compartments accept optional core locks for secure document storage | |
| Reversible configuration option | Return can be specified for left or right side orientation to fit office layout | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Primary use for senior managers, directors or CEOs requiring large work surface | |
|---|---|---|
| Management workstation | Supports daily computer work, document review, and small in-desk meetings | |
| Commercial open-plan manager area | Suitable for partitioned management zones in corporate office spaces | |
| Home office executive setup | Fits large dedicated home offices requiring professional workspace and storage | |
| Paired with high-back executive chair | Designed to match ergonomic high-back leather office chairs for seated use | |
| Combined with matching wall storage cabinet | Coordinates with matching wood/taupe bookcase and filing cabinet for cohesive office suite |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for commercial office use | |
|---|---|---|
| EN 14073-2:2004 | Storage furniture strength and stability requirements for office cabinet sections | |
| EN 13722:2004 | Furniture formaldehyde emission requirements for wood-based panels |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade ≤0.124mg/m³ | |
| GB/T 4897.3-2015 | Requirements for particleboard used in furniture construction |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade ≤0.124mg/m³; 3. GB/T 4897.3-2015: Requirements for particleboard used in furniture construction; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
