| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2450 x 1850 x 750 mm | |
|---|---|---|
| Worktop thickness | 25 mm | |
| Main work surface depth | 800 mm | |
| Side return width | 1200 mm | |
| Knee clearance height | 680 mm | |
| Knee clearance width | 1200 mm | |
| Modesty panel height | 450 mm | |
| Cable grommet diameter | 76 mm | |
| Drawer internal depth | 450 mm | |
| Open return shelf height | 300 mm | |
| Leg tube wall thickness | 1.5 mm | |
| Edge banding thickness | 2 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Worktop static load capacity | 136 kg | |
|---|---|---|
| Ball bearing drawer slide cycle rating | 50000 cycles | |
| Recommended user weight capacity | 150 kg | |
| Net product weight | 95 kg | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Leveling foot adjustment range | 10 mm | |
| Product warranty period | 10 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop panels | 25mm E1 grade engineered wood with light oak melamine laminate | |
|---|---|---|
| Accent panels and modesty panel | 18mm E1 grade engineered wood with white matte melamine finish | |
| Support legs | White powder-coated carbon steel with angled A-frame design | |
| Edge trim | 2mm thick PVC edge banding with chamfered finish | |
| Drawer hardware | Zinc-plated steel ball bearing full-extension slides | |
| Leveling feet | Injection-molded nylon with steel threaded insert | |
| Drawer pulls | Brushed silver anodized aluminum vertical bar pulls | |
| Cable port | Silver ABS flip-top wire management grommet | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Side return storage | Right-side return with 2 pull-out drawers and 1 lower open storage shelf | |
|---|---|---|
| Cable management | Flip-top desktop grommet routes power and data cables to under-desk space | |
| Leveling adjustment | Threaded nylon feet adjust 10mm to stabilize desk on uneven flooring | |
| Work surface zoning | Main zone for monitor/laptop use, return zone for document staging or printer placement | |
| Knee space access | Open central bay accommodates standard ergonomic office chairs with 680mm vertical clearance | |
| Privacy screening | Front modesty panel blocks view of seated user's legs from office entryways | |
| Orientation option | Return is configurable for left or right side installation per office layout needs | |
| Modesty panel integration | Panel attaches directly to worktop underside with hidden metal connectors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Designed for manager or director private workspaces, with formal two-tone aesthetic and storage capacity | |
|---|---|---|
| Open plan manager workstation | Suitable for open office team lead positions, with integrated cable management to reduce workspace clutter | |
| Home executive office | Fits high-end home workspaces, combining professional functionality with modern light oak residential aesthetic | |
| Small conference meeting space | Sized to accommodate 2 additional seated guests for impromptu desk-side meetings | |
| Office reception admin workspace | Works for senior reception or admin staff roles requiring both active work and document storage | |
| Recommended pairing | Pair with high-back ergonomic mesh office chair, 27-inch monitor, and under-desk mobile CPU holder |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements, applicable to desk performance validation | |
|---|---|---|
| EN 527-2:2016 | Office worktables dimensional and mechanical safety requirements, applicable to clearance and stability checks |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Office desk products performance standard, applicable to load and durability acceptance | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable to material emissions and environmental attribute validation |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to engineered wood desk construction | |
|---|---|---|
| GB/T 3327-2016 | Performance and test standards for office desks and worktables, applicable to structural load validation | |
| GB 18584-2001 | Interior decoration material limit of formaldehyde emission for wood furniture, applicable to panel material acceptance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to engineered wood desk construction; 2. GB/T 3327-2016: Performance and test standards for office desks and worktables, applicable to structural load validation; 3. GB 18584-2001: Interior decoration material limit of formaldehyde emission for wood furniture, applicable to panel material acceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
