Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall footprint | 2130 x 2130 x 760 mm | |
|---|---|---|
| Main desktop width | 1800 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Drawer slide dynamic load per drawer | 45 kg | |
| Drawer slide operational cycle life | 50000 cycles | |
| Cabinet hinge operational cycle life | 80000 cycles | |
| Cable grommet cable support capacity | 10 kg | |
| Laminate finish abrasion resistance | 2000 cycles | |
| Desk unit lateral stability load | 80 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Desktop substrate | 18mm E1-grade engineered wood core with high-pressure dark matte laminate top surface and 2mm brushed gold PVC edge banding | |
|---|---|---|
| Side return work surface | 18mm E1-grade engineered wood with matching dark matte laminate finish and matching gold edge trim | |
| Cabinet carcass | 18mm E1-grade particleboard with dark matte melamine finish, joined with confirmat screw assembly for rigid structure | |
| Front modesty panel | 15mm MDF core with diamond-pattern embossed dark finish, mounted flush below main desktop front edge | |
| Plinth base | 20mm engineered wood frame with gold accent trim, fitted with adjustable leveling feet for uneven floor adjustment | |
| Edge trim accents | 0.8mm thick brushed gold metallic PVC edge banding applied to all exposed desktop and cabinet perimeter edges |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Cable management | 80mm diameter desktop cable grommet routes power and data cables to under-desk cavity, supporting 10kg of cable and adapter weight | |
|---|---|---|
| Pedestal storage | Left fixed return includes 2 storage drawers and 1 hanging file drawer on full-extension slides, providing 0.32 cubic meters of enclosed storage | |
| Leveling adjustment | 4 adjustable 10mm-travel leveling feet on plinth base compensate for uneven floor surfaces up to 5mm of floor slope | |
| Seated access | 1100mm wide x 620mm high knee clearance accommodates standard executive office chairs with 50mm of lateral movement room |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.5 |
|---|
Standards applicable to China-market projects
| GB/T 4897.3-2015 Particleboard for general use - Part 3 | Requirements for furniture-grade boards, applicable to core material strength acceptance for cabinet panels |
|---|
This product must meet the following technical requirements: 1. GB/T 4897.3-2015 Particleboard for general use - Part 3: Requirements for furniture-grade boards, applicable to core material strength acceptance for cabinet panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
