Product supplierModern Light Wood Lift-Top Smart Coffee Table with LED Storage and Charging Station, 18mm thick MDF/particleboard core with light oak wood grain laminate finish
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 600 × 480 mm | |
|---|---|---|
| Lifted tabletop height above floor | 615 mm | |
| Lift mechanism vertical travel | 215 mm | |
| Raised lift-top work surface size | 800 x 400 mm | |
| Left enclosed storage module dimensions | 600 x 600 x 480 mm | |
| Open fluted shelf interior clearance height | 200 mm | |
| Tabletop panel thickness | 25 mm | |
| Plinth base height from floor | 50 mm | |
| Side control panel mounted height | 240 mm | |
| Rounded corner radius on storage module | 30 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static distributed load capacity | 80 kg | |
|---|---|---|
| Maximum load for raised lift-top panel | 5 kg | |
| Net product weight | 38 kg | |
| Storage compartment total volume | 120 L | |
| LED strip operational lifespan | 30000 hours | |
| Charging module maximum output | 18 W | |
| Lift mechanism cycle rating | 10000 operations | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm thick MDF/particleboard core with light oak wood grain laminate finish | |
|---|---|---|
| Left storage cabinet side panels | 15mm thick engineered wood with matching wood grain laminate, rounded edge profile | |
| Front fluted decorative panel | 12mm thick MDF with matte cream/light beige vertical ribbed texture | |
| Lift mechanism hardware | 1.5mm thick powder-coated steel lift arms with soft-close buffer hinges | |
| Plinth base trim | Matte light grey PVC edge-banded engineered wood | |
| Integrated LED lighting | Low-voltage 2835 SMD LED strip with diffused polycarbonate cover, warm white output | |
| Side control/power panel | Matte silver ABS plastic housing with illuminated indicator lights and power/USB ports | |
| Fixed lower table surface (left section) | 15mm thick engineered wood with matte light grey/stone effect laminate finish | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lift-top work surface operation | Manually operated spring-assisted lift that locks at full raised height for dining/laptop use, soft-close lowering | |
|---|---|---|
| Integrated charging station | Recessed cutout in raised tabletop housing 2 AC outlets, 1 USB-A port, 1 USB-C port for device power | |
| Ambient LED lighting control | Side panel touch controls for on/off and brightness adjustment, warm white diffused glow under raised top | |
| Enclosed storage access | Hidden compartment under raised lift top accessible by lifting the top panel, fixed left storage volume for large items | |
| Open shelf storage | Recessed fluted-front open shelf under raised top for frequently accessed items or display, integrated LED illumination | |
| Surface maintenance property | Stain-resistant and water-repellent laminate finish that wipes clean with a damp cloth, no special coating required | |
| Safety design feature | Rounded soft corners on all protruding edges and soft-close hinges to prevent finger pinching during lift operation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Small apartment living room use | Dual function as low coffee table and raised dining/work surface to save space in compact open-plan layouts | |
|---|---|---|
| Home office lounge area placement | Integrated charging and raised work surface supports temporary laptop work or device charging in reception/relaxation zones | |
| Modern minimalist interior matching | Light wood and cream fluted finish coordinates with Scandinavian, wabi-sabi, and contemporary neutral decor schemes | |
| Home media room use | Open and closed storage holds remote controls, media accessories, with ambient lighting for low-light viewing environments | |
| Hotel lounge or serviced apartment furnishing | Durable easy-clean surface and multifunction design suits short-stay accommodation guest seating areas |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 312:2010 | Particleboard performance specification, applicable for engineered wood substrate load and durability validation | |
|---|---|---|
| EN 62471:2008 | Photobiological safety for LED lighting products, applicable for integrated strip light eye safety assessment |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural integrity and finish quality inspection | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for substrate formaldehyde emission and structural strength verification | |
| GB 7000.204-2008 | Safety requirements for built-in furniture lighting systems, applicable for LED module electrical safety checks |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural integrity and finish quality inspection; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for substrate formaldehyde emission and structural strength verification; 3. GB 7000.204-2008: Safety requirements for built-in furniture lighting systems, applicable for LED module electrical safety checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
