Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 1800 x 750 mm | |
|---|---|---|
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Whole desk net weight | 185 kg | |
|---|---|---|
| Main worktop static load capacity | 150 kg | |
| Recommended maximum user weight | 150 kg | |
| Product service life | 10 years | |
| Surface abrasion resistance | 2000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Worktop surface | High-pressure walnut grain laminate, scratch-resistant finish | |
|---|---|---|
| Worktop core | 18mm thick P2 grade particleboard core | |
| Left support leg | 3mm thick powder-coated matte black steel, angled cantilever design | |
| Modesty panel | 25mm thick matte grey stone-veneer composite panel | |
| Storage cabinet body | 18mm thick walnut grain melamine faced particleboard | |
| Cabinet end panel | 25mm thick matte grey lacquered MDF panel | |
| Cabinet ventilation grilles | Cut-out ABS plastic inserts with horizontal slots | |
| Leveling feet | Nylon base adjustable glides, 15mm adjustment range | |
| Edge banding | 2mm thick PVC edge banding matching worktop finish | |
| Cable grommets | ABS plastic recessed cable access covers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm |
Adjustment / rotation / tilt / mobility / storage features
| Cable management system | Recessed central worktop cable port with internal routing to cabinet vents | |
|---|---|---|
| Integrated side storage | 3 soft-close drawer units for files and office supplies, full extension slides | |
| Cantilever leg design | Angled left support creates open knee space without obstructive front legs | |
| Adjustable leveling glides | Threaded nylon feet adjust to compensate for uneven floor surfaces | |
| Worktop layout zoning | Main work zone for monitor and keyboard, return zone for document and peripheral placement | |
| Ventilated cabinet design | Horizontal side vents allow passive airflow for stored IT equipment | |
| Modesty panel coverage | Full-height grey modesty panel shields user lap area from front view | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Executive private office | Fits 20sqm and above dedicated manager or director offices as primary work surface | |
|---|---|---|
| Corporate boardroom side desk | Serves as a supplementary work and storage surface in high-end meeting rooms | |
| High-end home office | Suitable for premium residential home offices with modern industrial interior design | |
| Law firm partner office | Ideal for professional service firm offices requiring storage and prestigious appearance | |
| Recommended configuration | Pair with matching high-back executive leather chair and mobile file pedestal for full setup |
EU Market Access Requirements* EN Standards
| Office desk safety requirements | EN 527:2011 Office furniture - Worktables and desks - Part 1: Dimensions | |
|---|---|---|
| Structural stability | EN 527:2002 Office furniture - Worktables and desks - Part 2: Mechanical safety requirements | |
| Surface chemical resistance | EN 12720:2009 Furniture - Assessment of surface resistance to cold liquids |
US and Canada office-furniture standards
| Desk load and durability | ANSI/BIFMA X2021Desk Products - Tests for durability and structural performance |
|---|
Standards applicable to China-market projects
| Desk dimensional tolerance | GB/T 3324General technical requirements for wooden furniture | |
|---|---|---|
| Surface durability | GB/T 4893.8Furniture surface test for abrasion resistance | |
| Formaldehyde emission | GB 18584Indoor decoration materials: limit of formaldehyde emission for wooden furniture | |
| Hardware performance | GB/T 10357.1Furniture mechanical test for tables: strength and durability |
This product must meet the following technical requirements: 1. Desk dimensional tolerance: GB/T 3324General technical requirements for wooden furniture; 2. Surface durability: GB/T 4893.8Furniture surface test for abrasion resistance; 3. Formaldehyde emission: GB 18584Indoor decoration materials: limit of formaldehyde emission for wooden furniture; 4. Hardware performance: GB/T 10357.1Furniture mechanical test for tables: strength and durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
