Automatic mm / inch conversion · Core engineering specifications
| Overall L-shaped footprint | 2800 x 2200 x 760 mm | |
|---|---|---|
| Main desktop depth | 1200 mm | |
| Side return length | 1600 mm | |
| Side return depth | 630 mm | |
| Desktop thickness | 90 mm | |
| Bullnose edge band thickness | 20 mm | |
| Central seated knee clearance width | 800 mm | |
| Seated knee clearance height | 650 mm | |
| Integrated leather writing pad dimensions | 900 x 600 mm | |
| Cable grommet diameter | 60 mm | |
| Drawer panel thickness | 15 mm | |
| Drawer base panel thickness | 5 mm | |
| Modesty panel height | 600 mm | |
| Pedestal storage unit width | 700 mm | |
| Finished Top Thickness | 50 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat |
Net weight / load capacity / users / durability
| Desktop static uniform load capacity | 150 kg | |
|---|---|---|
| Ball-bearing drawer slide cycle rating | 50000 open/close cycles | |
| Hinge cycle rating | 80000 open/close cycles | |
| Surface scratch resistance rating | 2000 abrasion cycles | |
| Net weight range | 220 kg | |
| Recommended user weight capacity | 150 kg | |
| Warranty period | 5 years | |
| Available color options | 4 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Desktop substrate | E0-grade high-density fiberboard with 0.8mm natural mahogany veneer | |
|---|---|---|
| Edge banding | Solid mahogany hardwood with rounded bullnose profile | |
| Desktop finish | High-gloss scratch-resistant PU paint finish | |
| Central writing inlay | Top-grain black leather with non-slip fabric backing | |
| Front modesty panel | Stained hardwood with carved geometric key trim and central embossed medallion | |
| Drawer hardware | Zinc alloy pulls with rust-proof treated steel ball-bearing slides | |
| Cable grommets | Brushed metal finish ABS plastic cable pass-throughs | |
| Base leveling glides | Nylon-padded adjustable steel glides | |
| Pedestal structural frames | Solid hardwood frame with veneered panel infills | |
| Wood moisture content | 10% | |
| Locks | Zinc alloy central locking system for all pedestal drawers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up |
Adjustment / rotation / tilt / mobility / storage features
| Pedestal storage configuration | 2 side pedestals with 2 box drawers and 1 locking file drawer per unit | |
|---|---|---|
| Cable management system | 2 desktop grommets with under-desk routing channel for power and data cables | |
| Leveling adjustment | 15mm height adjustment on base glides to compensate for uneven floors | |
| Drawer operation | Smooth full-extension ball-bearing slides with soft-close damping | |
| Central locking mechanism | Single key lock secures all pedestal drawers for document security | |
| Return configuration | Fixed right-side attached return for auxiliary work and meeting space | |
| Surface protection | Heat, stain and scald resistant PU finish supports hot beverage and office equipment placement | |
| Cable access cover | Rotating grommet caps allow cable routing while maintaining clean desk appearance | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | Main top 2500× 1050× 350 mm; return/pedestal packed separately | |
| Reference Packaged Gross Weight | 180 kg/set in 4 cartons | |
| Reference Packaging Volume | 1 m³/set |
Recommended spaces / users / usage modes
| Private executive office | Sized for CEO, director or senior manager private office spaces with 30sqm+ floor area | |
|---|---|---|
| Executive meeting use | Right-side return supports small 2person informal meetings across the desk surface | |
| Traditional office interiors | Red mahogany carved design matches classic Chinese or traditional formal office decor schemes | |
| Heavy daily office use | Durable construction supports 8+ hours daily use with computers, documents and office equipment | |
| Matching furniture sets | Pairs with matching high-back leather executive chairs, filing credenzas and office bookcases | |
| Formal reception work area | Formal front appearance supports hosting visitor meetings directly at the desk |
EU Market Access Requirements* EN Standards
| EN 527-1:2011 | Office worktables safety and strength requirements for desk structural performance | |
|---|---|---|
| EN 13722:2004 | Office furniture storage units strength and durability for pedestal drawers | |
| EN 12720:2009+A1:2013 | Furniture surface resistance to cold liquids for desktop finish performance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard for static load, durability and stability performance | |
|---|---|---|
| ANSI/BIFMA X5.9-2019 | Storage units standard for drawer slide cycle and load performance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden office furniture, applicable to structural and finish performance | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E0 grade emission requirement ≤0.05mg/m³ | |
| GB/T 4897.3-2003 | Particleboard/fiberboard specification for furniture structural substrate use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden office furniture, applicable to structural and finish performance; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E0 grade emission requirement ≤0.05mg/m³; 3. GB/T 4897.3-2003: Particleboard/fiberboard specification for furniture structural substrate use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
